Bridgelux Meanwell Reliable Factory LED Highbay 5 years Warranty

Bridgelux Meanwell Reliable Factory LED Highbay 5 years Warranty

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Product name	Factory LED Highbay
Material	Aluminium
Input voltage	90-295VAC
LED chip	USA Bridgelux 45mil
Driver	UL listed Meanwell driver
Light Source	Energy-saving Lamp
IP	IP65
Material	Aluminum, Aluminum Die Casting, PC, PVC, Silicone, Steel
Voltage	90-260V

Detail Description

Bridgelux Meanwell Reliable Factory LED Highbay 5 years Warranty

Advantage of Factory LED highbay

· Original USA Bridgelux 45mil chip;
· Original UL listed Meanwell driver;
· 5 years warranty;
· Unique patent high quality goods;
· Advanced aluminium Heat Sink dissipation reduce temperature >20℃;
· Can be applied in high / low temperature environment;
· CRI>80 comply with European Standard,
high CRI providing human eyes acceptable quality of light;
· Lighting solutions can be offered from our engineering team;
· Good & Professional pre-sale / after-sale service;

Our Range of LED High Bay Lights
Model	Power (W)	Input Voltage	Lumen (lm)	Radiator Dimension (mm)	Net Weight (kg)
YWHBFM-100-080	100	AC85-265VAC	8696lm	￠210* H120mm	5.1
YWHBFM-100-120	100	AC85-265VAC	9782lm	￠210* H120mm	5.1
YWHBFM-120-080	120	AC85-265VAC	9815lm	￠210* H120mm	5.1
YWHBFM-120-120	120	AC85-265VAC	11046lm	￠210* H120mm	5.1
YWHBFM-150-080	150	AC85-265VAC	12679lm	￠210* H135mm	5.3
YWHBFM-150-120	150	AC85-265VAC	14220lm	￠210* H135mm	5.3
YWHBFM-180-080	180	AC85-265VAC	14600lm	￠210* H135mm	5.3
YWHBFM-180-120	180	AC85-265VAC	16330lm	￠210* H135mm	5.3
YWHBFM-200-080	200	AC85-265VAC	15386lm	￠210* H135mm	5.3
YWHBFM-200-120	200	AC85-265VAC	17218lm	￠210* H135mm	5.3

LED chips Brand	Chips type	LED Efficiency	CRI	CCT	Warranty
Bridgelux chip	COB	120LM/W	>80	WW/NW/CW	5 Years
Phiplips chip	SMD
CREE chip
Osram

Driver details
Brand	Taiwan Meanwell
Model	HLG Series
Input Voltage	90-305VAC
Driver efficiency	>0.9
Gurantee	5 years

Heat Sink details
Material	Strectched Aluminium 6063
Feature	Special design & Patent
Net Weight	5.3KG
Size	￠210* H135mm
Heat Dispatch Method	Active cooling by fan

Application of Factory LED highbay

Suitable for Warehouses, Production and logistics workshops, Retail stores,

Theme restaurants, Amusement parks, Indoor stadiums and public places,

and other industrial and commercial lighting purposes.

Packaging of Factory LED highbay

a). Separately packaged of LED high bay light unit & lamp shade;

b). 2PCS/CTN for 100W – 240W LED high bay light,

20PCS/CTN for 80/90/120 degree aluminium reflectors;

While 10PCS/CTN for PC cover;

c). All packaged with good packaging material, paper angle bead available for lamp shades;

d). For sample, we suggest shipping via courier, like DHL, UPS, FEDEX; for bulk order, we suggest by Air & by Sea (FCL or LCL).

Installation of Factory LED highbay

Testing & Aging LED highbay

1. Every single light tested;

2. 24 hours Aging;

3. Impact test several times.

YOUWIN LED high bay light quality control

1. Before the order to be confirmed, we should check the material &
colour temperature by sample which should be strictly controlled;

2. We will trace the different phase of production from the beginning;

3. Every LED light tested & quality checked and cleaned before packing;

4. Before delivery clients could send one QC or point the third party to
check the quaity;

5. We will try our best to help clients when problem occurred.

YOWIN Factory & Team

· Focus on LED high bay light
· With years’ experience in research & development
· High reputation, reliable LED supplier

Certificates & Warranty of Factory LED highbay

1.CE RoHS certificates for Europe market;

2. SAA approvals for Austrilian & New Zealand market;

3. SASO Testing report available, SASO certificate for Saudi Arabia market.

YOUWIN at Hongkong Lighting Fair

FAQ:

Q: Your company history？

A: 4 years, from 2010.

Q: What\'s your max capability per month?

A: 5000PCS/MONTH.

Q: How about your quality control?

A: We treat quality as first, applied IS09001:2008 quality system, and our workers are professional on Highbay we focus on.

Q: Do you have any testing equipment?

Yes, we have Integrating Sphere to test lumen, voltage, PF, CRI, efficiency etc.

Q: How long is your warranty on Highbay?

A: 5 yeas, we can send you a copy of Warranty Agreement signed between us.

Trading process & Partners of Factory LED highbay

If any intest of YOUWIN factory LED highbay, please feel free to contact us.

You are welcomed at any time.

Additional Information

Payment Terms	L/C, T/T, D/A, D/P, Credit Card, Western Union, Money Order, Paypal, Others
Minimum Order	60
Lead Time / Delivery Time	1 Day(s)
Sample Available	YES
Delivery Details	30% deposits before production, 70% balance to be paid before delivery. 3 days for sample, 7-10days for bulk order.
FOB Port	Shenzhen,
Loading Info	By Sea, by Air, by Express.
Packing Info	Light Body:Carton size : L53W34H38 cm ( 2pcs/ctn)Net weight :10.6 KG/CTNGross weight :13.0KG/CTN
Target Market(s)	Oceania, Eastern Europe, Western & Southern Europe, Northern Europe
