2 port HDMI splitter with IR function

2 port HDMI splitter with IR function

FEATURES

lOne HDMI input signal split to two HDMI sink devices

lSupport 3D

lSupport CEC

lSupport deep color 30bit, 36bit

lWith built-in IR extender function

lSupport Blue-Ray 24/50/60fs/HD-DVD/xvYCC

lDigital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

lSupport signal retiming

lSupport input up to 15metres AWG26 HDMI standard cable length,

output distance up to 25metres AWG26 cable length

lNo loss of quality

lInstalls in minutes

lNeed DC5V/1A power supply

SPECIFICATIONS:                                       HDSP0102IR

 HDMI resolution ………………………....24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i

 Support video color format …………………………..…………….24bit/deep color 30bit,36bit

 Support audio format……………….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

 Max bandwidth……………………………………………………………………………..225MHz

 Max baud rate……………….…….………………….…………………………………..6.75Gbps

 Input/Output TMDS signal ………….…………………………..……...… 0.5~1.5Volts p-p(TTL)

 Input/Output DDC signal ……………………………………………..………… 5Volts p-p (TTL)

 Input cable distance..…... …………….………………….≤15m AWG26 HDMI standard cable

 Output cable distance……………………………….…...≤25m AWG26 HDMI standard cable

 Max working current…………………………………………………………………….....800mA

 Power adapter format..Input: ……….…....AC (50HZ, 60HZ) :100V-240V; Output: DC5V/1A

 Operating Temperature range……...…………….……………………………… (-15 to +55°C)

 Operating Humidity range………………………….….……….5 to 90%RH (No Condensation)

 Dimension (L x W x H)     ……………………………….……………….………110X52X20 (mm)

 Weight…..………………………………………………………..…….…..……………………190g
