cob led high bay light industrial lamp
  • cob led high bay light industrial lamp
  • cob led high bay light industrial lamp
  • cob led high bay light industrial lamp
  • cob led high bay light industrial lamp
cob led high bay light industrial lamp
cob led high bay light industrial lamp
cob led high bay light industrial lamp
cob led high bay light industrial lamp

cob led high bay light industrial lamp

Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Product Description
Product Description
  • Product Details

Basic Specification

Beam Angle 360degree
Lumen 14000lm
CRI >70Ra
LED Quantity 1820pcs smd led
Dimensions 118*330mm
Light Source LED
Material Aluminum, PVC
IP IP44
Voltage 90-260V

Detail Description

cob led high bay light industrial lamp

Specifications of our led high bay light:


Item

Specifications

Parameter

Electrical

Input Voltage

AC100-277V



Input  Current

1.28A/100V,



Power Consumption

120±10%W



Power Factor

  >0.9



Frequency Scope

50/60Hz



Operating Temperature

-20~40°C

Photometric

Socket type

E40



Work Environment

Indoor use



Lighting Source

3528SMD LED



Beam Angle

360°



Life span

>35000h



Led qty

1820pcs

Part Number

Lumens

 (LM)

Illuminance(lux) ±10%

CRI

CCT





1m

2m

3m

4m

5m

6m





HD-CE40-W1820Z-A00C



14500±10%

720

339

185

122

80

47

≥73a

5000- 7000K

14300±10%

700

329

179

119

78

46

≥73a

3800- 4500K

14200±10%

679

319

174

115

76

45

≥73a

2700- 3500K



Notes: testing without lampshade ,on environment temperature 25°C±5%,80 RH %





Showroom of our led high bay light:





Features & advantages of our led high bay light:

1. Beam Angle: 360 degree
2. It\'s major to replace the CFL with E40/E39 screwed lamp socket directly.
3.80% more energy saving compared with conventional street light, CFL, Incandescent light.
4. Estimated lifespan: >50, 000 hours
5. Cool/Pure/Warm white color, high CRI with great directionality
6. Fast turn on, no warm-up or cold start problems
7. Solve 4 difficulties for LED packaging, heat sinking, operational lifespan, luminous efficiency
8. Special surface design with arc, make sure the radiation diameter on the ground is accord with the  standards for size.
9. Aluminum with high conductivity, long-life fan and high quality driver, it can withstand high Temperature.



Applications of our led high bay light:

  • Warehouse, indoor lighting, street landscape.
  • Conference / Meeting rooms/  Commercial Complexes
  • Residential / Institution Buildings/ Schools, Colleges / Universities
  • Places where need energy saving and high color rendering index lighting



Package of our led high bay light:



Part No.

Net weight

   Box

                  Carton

Size (mm)

Gross weight

 Pcs/box

Size(mm)

Gross weight

box/carton

HD-CE40-W1820Z-A00C

0.85Kg

L400*W135*H140

1.1Kg

1

L580*W580*H420

19.5Kg

16



Sketch:

Additional Information

Payment Terms L/C, T/T, Western Union, Money Order, Paypal
Minimum Order 1pce
Lead Time / Delivery Time 5 Day(s)
Sample Available YES
Delivery Details 3-5days for samples, 7-10 days for bulk order
FOB Port Shenzhen,
Loading Info Via express, by air / sea.
Packing Info 1pce/box, 0.85kg, 400*135*140mm16pcs/1ctn, 19kg, 575*575*430mm
