Basic Specification
| LCD Type | Active matrix TFT-LCD |
|---|---|
| Frame | Black Metal |
| type | saw |
| Resolution | 4096*4096 |
| Touch Points | Multi-Touch |
| Touch Panel Size | 21-40 inch |
| Type | Surface Acoustic Wave |
| Operating Temperature | -20~70 centi degree |
Detail Description
specification:
Model No. |
KOT-0215US-SA4BCP |
|
Series |
OT,Dust-proof and Compact |
|
Display Type |
16:9 Ratio 21.5\"Active matrix TFT-LCD,LED backlight |
|
Active Area(display) |
18.76\"(476.64mm)×10.55\"(268.11mm) |
|
Monitor Dimensions |
Width: 511.7mm Width with brackets:535.7 mm Height with brackets: 322mm |
|
Suggested Resolution |
1920×1080 @ 60Hz |
|
Support Colors |
16.7M |
|
Brightness(Typ.) |
Pure LCD Panel |
250cd/m2 |
With SAW Glass Sensor |
225cd/m2 |
|
Response Time(Typ.) |
16ms |
|
|
Viewing Angle (Typ.at CR>10)) |
Horizontal(left/right) |
89°/89° |
Vertical(up/down) |
89°/89° |
|
Contrast Ratio(Typ.) |
5000:1 |
|
Video Input |
VGA ,DVI |
|
Frequency(H/V) |
30~80KHz / 60~75Hz |
|
Power Supply |
Type: External brick |
|
Environment |
Operating Temp. |
0~50°C |
Storage Temp. |
-20~60°C |
|
Operating RH: |
5%~90% |
|
Storage RH: |
5%~90% |
|
MTBF |
30,000 Hours |
|
LCD Back light Life(Typ.) |
30,000 Hours |
|
Weight(N.W/G.W) |
5.7Kg / 7.8Kg (Approx.) |
|
Power Consumption |
24W Max. |
|
Mount Interface |
1)VESA 75mm and 100mm 2)Mount bracket, horizontal or vertical (Standard mount brackets are supplied) |
|
OSD Control |
Buttons |
AUTO,+,POWER,-,MENU |
Function |
Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset |
|
Touch screen Type |
Keetouch 21.5\" SAW 4mm touch sensor |
|
Touch System Interface |
Having USB and Serial(RS232) interface |
|
Touch Response time |
USB/Serial: 8.4/10.4ms |
|
Agency Approval |
CCC,ETL,FCC,CE,RoHS |
|
Regular Warranty |
1 year |
Additional Information
| Payment Terms | L/C, T/T, Western Union, Paypal |
|---|---|
| Minimum Order | 1 |
| Lead Time / Delivery Time | 7 Day(s) |
| Sample Available | YES |
| Delivery Details | 1week after getting your firm order |
| FOB Port | Shenzhen |
| Loading Info | 1kit/carton |
| Packing Info | 1kit/carton.Dimension:56x49x20cm (1pcs/carton) or 53x25x46cm (2pcs/carton). |
| Target Market(s) | North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East |
