PH5mm LED display

PH5mm led display is definitely indoor used led display. Pixel density is 40000 dots per sqm which means it only need 1sqm play video.
High brightness, short viewing distance, big size, high definition, small pixel pitch make the indoor PH5mm SMD LED display an ideal resolution in all indoor advertising field. The viewing distance can be as short as 1 meter,

Main parameters of PH5 led display:

1. Physical Pixel Pitch: 5.0 mm

2. Physical Pixel Density: 40000 dots/m2

3. LED type: SMD3528

4. Module Size: 160mm*160mm

5. Module resolution: 32*32 dots

6. Cabinet size: 640mm*640mm

7. Cabinet resolution: 128*128

8. Max. power consumption: 1100 W/sq.m

9. Min. viewing distance: 3 m

10. Brightness: ≥ 2200CD/m2

11. IP grade: IP54 front side/IP54 backside

12. Operation Humidity (RH): 0-95%

13. Operating temperature (Celsius degree): -20～+55 degree

14. Servicing: front and back

15. Power supply: 100-240V/50-60HZ

16. LED Drive: constant-current drive

Additional Information

Minimum Order	1pc
Lead Time / Delivery Time	0 Day(s)
Sample Available	NO
Target Market(s)	Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe
