PH10mm LED display
PH10mm is the only high quality model both in outdoor and indoor series. If it is used outside, it has to be waterproof. There are 10000 dots per square meter. High resolution makes it popular, especially for mobile advertising.
When the size is more than 4 sqm, we will recommend it in video advertising. High resolution make pictures very clear even people stand closely to the screen.
Main parameters of the display:
1. Physical Pixel Pitch: 10 mm
2. Physical Pixel Density: 10000 dots/m2
3. LED type: SMD3528
4. Module Size: 160mm*160mm
5. Module resolution: 16*16 dots
6. Cabinet size: 960mm*960mm
7. Cabinet resolution: 96*96
8. Max. power consumption: 750 W/sq.m
9. Min. viewing distance: 6 m
10. Brightness: ≥ 1400CD/m2
11. IP grade: IP54 front side/IP54 backside
12. Operation Humidity (RH): 0-95%
13. Operating temperature (Celsius degree): -20～+55 degree
14. Servicing: front and back
15. Power supply: 100-240V/50-60HZ
16. LED Drive: constant-current drive
Additional Information
| Minimum Order | 1PC |
|---|---|
| Lead Time / Delivery Time | 0 Day(s) |
| Sample Available | NO |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
