Basic Specification
| color | white |
|---|---|
| CCT | 6000-6500K |
| IP | IP65 |
| Application | Architectural Lighting |
| Voltage | 90-260V |
| Material | Aluminum Die Casting, Glass |
| Finishing Color | White |
| Light Source | LED |
Detail Description
Key Specification:
Applications:
1.LED floodlight is widely used in square, building, aerodrome, dock, bus station, street, park and dooryard.
2.led floodlight contains Multi Voltage power adapter, and it works in different countries.
| Order Code | KDFL-XD30W | |
| Electrical Characteristics | Wattage | 30W |
| Input Voltage | AC85-265V | |
| Freqency Range | 50Hz~60Hz | |
| working Voltage | DC30-36V | |
| Power Factor | ＞0.98 | |
| Power Efficiency | ＞83% | |
| Toyal harmonic Distortion | ≤9% | |
| System Consumption | 32 W | |
| Led Consumption | 27 W | |
| Optical Characteristics | Luminous Efficiency | 75-85 lm/w |
| llluminance Uniformity | ＞0.4 | |
| Lamp\' Luminous Efficiency | ＞80% | |
| CCT | 3000-3500K / 4000-4500K / 5000-5500K / 6000-6500K | |
| Color Rendering Index | WW | Ra＞68 |
| PW,CW | Ra＞75 | |
| Led Initial Flux | WW | 1804 LM |
| PW | 1921 LM | |
| CW | 1941 LM | |
| Average llluminance | Height 2M | 213 Lux |
| Height 4M | 53 Lux | |
| Height 6M | 23 Lux | |
| llluminance Area | Height 2M | Round, diameter 4.9m |
| Height 4M | Round, diameter 9.7m | |
| Height 6M | Round, diameter 14.6m | |
| Light Distribution | Symmetrical/Rectangular | |
| Light Design | LED+Reflector secound light distribution | |
| General Characteristics | Led Junction Temperature | ≤80℃ |
| Working Temperature | -40℃- +55℃ | |
| Storage Temperature | -25℃- +65℃(25℃) | |
| IP Grade | IP65（outdoor use） | |
| Working Life-span | 50000H | |
| Warranty | 2 Years | |
| Lamp Body | Anodized Aluminum | |
| Optical Lens | Aluminum Alloy | |
| The color of the lamp shell | White | |
| Net Weight | 1.72 kg | |
| Power Line | 0.75m㎡ 3-core wire | |
| Connect wire | Live wire(L) | Brown |
| Neutral wire(N) | Blue | |
| Ground wire(G) | Yellow/Green | |
| Certificate | CE | |
| Packing | Pcs per ctn | 1pcs/carton |
| Dimensions | 250*160*130 mm | |
| Gross Weight | 2.1 kg |
1.LED floodlight is widely used in square, building, aerodrome, dock, bus station, street, park and dooryard.
2.led floodlight contains Multi Voltage power adapter, and it works in different countries.
Additional Information
| Payment Terms | L/C, T/T, Western Union, Paypal, Others |
|---|---|
| Minimum Order | 1pcs |
| Lead Time / Delivery Time | 5 Day(s) |
| Sample Available | YES |
| Delivery Details | sample production delivery time 3-5 days.quantity production delivery time 7-10 days |
| FOB Port | Shekou,Shenzhen |
| Loading Info | depends on customer requirement. |
| Packing Info | 1. 1pcs/carton / 2. packing size:250*160*130 mm / 3. a 20ft ISO container can accommodate 5300pcs. / 4. a 40ft ISO container can accommodate 11080pcs. |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
