wireless mini usb dvr

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Specification

Size	10.361.7 (cm)

USB DVR

ES-601WD4-Win7

Weight: 0.20 KG

Size:10.3*6*1.7 (cm)

Color box: 18.5*13*4 cm

Features:

Support win7 system

4ch video input.25fps(PAL),30fps(NTSC)

Quad display

Multi-alarm mode:sensor alarm,motion detection alarm,video lost alarm,insufficient disk space alarm

Timing recording and circle recording

MPEG4 compression,5 standard image quality setting

Support multi channel playback,channel,zoomin,snapshot,save data,print and backup function

Remotely surveillance,playback function supported

Automatically send alarm email

Support mobile phone view

System Requests:

CPU:Intel P4 Celeron Processor,1700MHz(0Min)

RAM:256M(Min)

Hard Disk:80GB(Min)

Operating system:Windows2000(above Sp4)/2003(above SP1)/XP(above Sp2) WIN7

USB Interface:2.0

Specification:

USB	2.0
Input interface	USB
Video input	RCA×4
Audio input	RCA×2
Viewing Frame rate	25fps(PAL),30fps(NTSC)
Recording frame rate	25fps(PAL),30fps(NTSC)
Compression format	MPEG4
Resolution	640x480/352x240(NTSC);704x576/352x288(PAL)
Recording backup	HDD,ZIP,U disk,CD-R/W
Recording Mode	Manual,timing,motion detect,sensor alarm
Remote transmission	TCP/IP
Transmission port	USB2.0
Internet protocol	IE browser,DDNS
CPU	Intel P4 Celeron processor,1700MHz(Min)
Mainboard	Intel 845/865/915 series
HDD	80G (Min)
Memory	256M (Min)
Graphics cards	GeForce2,GeForce4,FX5200,ATI Rage128
Operation system	Windows 2000(above SP4)/2003(above SP1)/XP(above SP2)
DirectX	9.0

Payment Terms	T/T, Others
Minimum Order	1PC
Lead Time / Delivery Time	3 Day(s)
Sample Available	NO
Delivery Details	3-5 business days after payment confirmed
FOB Port	Shenzhen
Loading Info	International Express Sea Air
Packing Info	gift box
Target Market(s)	North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East
