30x Intelligent security digital cameras speed dome cameras PTZ camera

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Specification

Mode	Analog Intelligent Auto Tracking Speed Dome
Preset speed	400°/S
Preset Points	256
Menu operation	Multi-Language (English Chinese German etc.)
relevant certification	CE,RoHs,FCC,IP66
Style	Dome Camera
Special Features	Other
Technology	Other, Pan, Tilt, Zoom
Type	Other
Image Sensor	CCD

27x Intelligent PTZ Speed Dome Cameras Waterproof Outdoor Cameras

Fuga7.82-27x (Outdoor)

Samsung SCM-2301, 30x optical zoom, 1/4\" Interline Transfer CCD, f=3.3 to 99.0mm(F 1.6 to 3.2) Color: 560 TVLine (Min.) B/W: 570 TVLine (Min.)
360° continuous rotation, tilt: 0° ~90° (180°auto flip), manual pan operation speed: 0.1~300°/S, manual tilt operation speed: 0.1~120°/S, preset running speed 400°/S, 256 presets;
Multi-language (English, Chinese, German, Polish etc. ) OSD menu screen display function, easy to set dome and camera Specifications;
24 programmable privacy zones, 8 groups programmable real-time operation areas ;
2 pattern scans and 6 programmable vector scan;
Support protocol: Pelco-D/P, Actiontop, Alec;
Intelligent power off memory function;
All weather proof design, IP66 Grade(outdoor type);
RS-485 long-range control

Model	Fuga7.81	Fuga7.82
Dome type	Indoor	Outdoor
Dome Camera
Address	0~255
Pan range	360° endless
Tilt range	0°~90° Flip; 180° auto flip with 10° forward tracing
Manual Pan speed	0.1~300°/Sec
Manual Tilt speed	0.1~120°/Sec
Preset speed	400°/Sec
Preset accuracy	±0.10°
Preset points	256
Function Parameters
Operation menu	Multi-Language (English , Deutsch, Espanol, etc)
Function display	Yes
Operation crosshair function	Yes
Pan and Tilt position display	Yes
Privacy zones (Masking)	24 Programmable Zones
Sector label display	8 Programmable Zones
Recall Function	Yes
PTZ Tours (Pattern)	2 Programmable (Pan/Tilt/Zoom and each tour is 120seconds)
Operation return function	Yes
Vector scan groups	6 Programmable(Dwell time speed preset point and embed other vector scan or PTZ tours)
Integrated communication protocol	Pelco_D/P Actiontop Alec
Auto Scan	with Smart Programmable variable speed
High efficient 3-dimension scan	Yes
Long-focus speed-limited	Yes
Intelligent power off real time memory	Power off memory of function set; automatic wakeup tour function
Home position	Yes
Supporting camera	Support Sony, Hitachi, Yoko, CNB, Sanyo, LG and Samsung etc
Camera menu operation	Yes
Manual operation	Endless
General parameters
IP66 for outdoor use	No	Yes
Operating Temperature	0°C~50°C	–30°C~60°C
Humidity	0%~90% (Non condensing)
Heater in operation	No	6°C on 14°C off
Power	24VAC /1.5A	24VAC / 2A
Consumption	20W	35W
Communication	RS485 (+/-)
Connection	BNC cable

Other compatible camera modules: Samsung 23x, 27x, 30x, 37x; Sony 18x, 26x, 28x, 36x; LG, Hitachi, CNB, etc;

Applicable places:

Our Factory sightview:

Packaging:

Payment Terms	T/T
Minimum Order	1
Lead Time / Delivery Time	7 Day(s)
Sample Available	YES
Delivery Details	5-7 working days
FOB Port	Guangzhou,Hong Kong
Loading Info	sea and air
Packing Info	4pcs for one standard carton
Target Market(s)	Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, Northern Europe, Central & Southern Asia, Southeast Asia, Western & Southern Europe
