1.3Megapixels HD IP IR Camera
  • 1.3Megapixels HD IP IR Camera
  • 1.3Megapixels HD IP IR Camera
  • 1.3Megapixels HD IP IR Camera
  • 1.3Megapixels HD IP IR Camera
1.3Megapixels HD IP IR Camera
1.3Megapixels HD IP IR Camera
1.3Megapixels HD IP IR Camera
1.3Megapixels HD IP IR Camera

1.3Megapixels HD IP IR Camera

Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Product Description
Product Description
  • Product Details

Basic Specification

Sensor 1/3\" progressive scan CCD
Effctive pixels 1280(H)×720(V)
relevant certification CE,RoHs,FCC,IP66
Lens 18X optical zoom f=4.7mm(W) ~ 84.6mm(T)
Memory interface Support image and video storage,SD2.0
Style Dome Camera
Special Features Other, Vandal-proof, Waterproof
Type IP Camera
Image Sensor CMOS
Technology Infrared, Other, Pan, Tilt, Zoom

Detail Description




1.3Megapixels HD IP IR Camera

Mega4.GU

  • New type high power IR-III LEDinfrared lamp,auto-dimming technology,better night vision, IR irradiation distance can reach 150M;
  • 1.3 megapixels,adopt 1/3\" progressive scan CCD sensor,18X optical zoom。
  • Optimized H.264 Main Profile compression algorithm,high compression ratio, high definition, support dual stream;
  • Adopt SOC Hi3512 processor,high integration;
  • Support multi-IP protocol, such as TCP/IP、UDP、RTP、RTSP、RTCP、HTTP、DNS、DDNS、DHCP、FTP、NTP、PPPOE、SMTP、UPNP;
  • Support bothway voice talkback and monitoring;
  • Heater and radiator function, make the product apply to wider work environment and running more stable.
  • Unusual automatic recovery and auto reconnect once network interrupted;
  • Support setup and call of preset, tour and track;
  • Built-in Web Server, can realize remote monitor, control, set and other operations through IE browser;
  • Support phone and mobile network monitoring;
  • Support ONVIFprotocol
  • Pass IP66,CE,FCC,RoHs and other related validation;
  • 1 channel input alarm and 1 channel output alarm, support hard reset , image and video storage;

Mode Mega5.GU
Hardware
cpu ARM9,32 bit RISC
SoC Hi3512
RAM 128MB
ROM 16MB
Network LAN Realtek 10/100M BASE-TX
Camera
Sensor 1/3\" progressive scan CCD
Effctive pixels 1280(H)×720(V)
Total pixels 1.3 megapixels
Lens 18X optical zoom f=4.7mm(W) ~ 84.6mm(T)
Iris F1.6 ~F2.8
Horizontal angle 55.2°(W)~3.2°(T)
Min. illumination Color: 0.5 Lux \\ B/W:0.02 Lux
SNR ≥50db(AGC OFF,Weight On)
Electronic shutter 1/50—1/10000sec
Interface
Voice talkback output 1 channel,MIC port(optional)
Audio output 1channel,linear output(optional)
Analog video output Support
Input alarm 1 channel
Output alarm 1 channel
Hard reset Support
Memory interface Support image and video storage,SD2.0,
Compression
Video compression  H.264 Main Profile@Level 3.0 / MJPEG selectable
Max. image resolution Preferred stream:1280x960、1280x720 (selectable)
Alternated stream:640x480
Video compressed code 32Kbps~16Mbps setable
OSD title Support channel name, date and video information overlay; OSD position adjustable
Audio compression G.726/G.711A/G.711U
Mask setting Max 4 Zones selectable
Dual stream Support
Email alarm Support
Protocol TCP/IP、UDP、RTP、RTSP、RTCP、HTTP、DNS、DDNS、DHCP、FTP、NTP、PPPOE、SMTP、UPNP
ONVIF protocol Support
Motion detection Support intelligent mobile phone with Windows Mobile 6,Symbian V3/5 version , iPhone and Android system
Dome
Horizontal rotation range 360° infinit contionuous rotation
Tilt rotation range 0°~90°  auto flip 180°
Pan manual operation speed 0.1~250°/S
Tilt manual operation speed 0.1~200°/S
Preset running speed 120°/S
Preset accuracy ±0.20°
Preset number 128
Power off memory Power off momory function, auto wakeup tour function
Working temperature -30℃~60℃
Working humidity 0% - 90%
Power supply 24VAC 3A 60Hz/50Hz
Comsuption 40W (outdoor)
IR parameters
Number of ∮20 lamps 9
IR distance 150M
Flashlight Have
Related validation IP66,CE,FCC,RoHs
