1080P Network Synchronized Zoom Infrared ir outdoor ptz camera
  • 1080P Network Synchronized Zoom Infrared ir outdoor ptz camera
  • 1080P Network Synchronized Zoom Infrared ir outdoor ptz camera
  • 1080P Network Synchronized Zoom Infrared ir outdoor ptz camera
  • 1080P Network Synchronized Zoom Infrared ir outdoor ptz camera
1080P Network Synchronized Zoom Infrared ir outdoor ptz camera
1080P Network Synchronized Zoom Infrared ir outdoor ptz camera
1080P Network Synchronized Zoom Infrared ir outdoor ptz camera
1080P Network Synchronized Zoom Infrared ir outdoor ptz camera

1080P Network Synchronized Zoom Infrared ir outdoor ptz camera

Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Product Description
Product Description
  • Product Details

Basic Specification

IR distance 150M
Lens 20X optical zoom f= 4.7 mm (WIDE) to 94.0 mm (TELE
Pixels HD:1920X1080=2 megapixels
Sensor 1/2.8 type
Video compression H.264 Main Profile@Level 3.0 / MJPEG selectable
Style Dome Camera
Type IP Camera
Special Features Vandal-proof, Waterproof, Weatherproof
Image Sensor CMOS
Technology Infrared, Other, Pan, Tilt, Zoom

Detail Description



1080P Network Synchronized Zoom Infrared ir outdoor ptz camera


Mega5.GB-S

  1. Global initiative technology for synchronous zoom infrared cameras with infrared lamp emission angle changeable in accordance with camera zoom;
  2. 9 inches housing with single lamp design, easy installation;
  3. IR distance can reach over 150M;
  4. Adopt 1/2.8” type \"Exmor\" CMOS sensor, 20X optical zoom, 2.0 Mega Pixels (1920X1080);
  5. Adopt SOC Hi3515 processor, high integration;
  6. Optimized H.264 Main Profile compression algorithm, high compression ratio, high definition, support dual stream;
  7. Can setup image quality, code rate and frame rate;
  8. Support video loss, motion detection( sensitivity and detection area can be set) and sensor alarm function;
  9. Support two-way audio and monitoring;
  10. Support multi-IP protocol, such as TCP/IP/UDP/RTP/RTSP/RTCP/HTTP/DNS/DDNS/DHCP/FTP/NTP/PPPOE/SMTP/UPN;
  11. Support abnormal situation automatic recovery and network interruption auto reconnection;
  12. Support setup and call of preset, tour and track;
  13. Can realize remote monitor, control, setup and other operations through IE browser or other IP software, like NVS center, Milestone, Digifort, NUUO, etc.;
  14. Support phone and mobile network monitoring;
  15. Support ONVIF protocol;
  16. With 1 channel input alarm and 1 channel output alarm, support hard reset , image and video storage;
  17. With Heater and radiators, making the camera to run more stable under temperature of -30℃~60℃;
  18. With certificate of IP66,CE,FCC,RoHs and other related validation;

Model  Mega5.GB-S
Hardware
CPU ARM9,32 bit RISC
SoC Hi3515
RAM 128MB
ROM 16MB
LAN Realtek 10/100M BASE-TX
Camera
Sensor 1/2.8 type \"Exmor\" CMOS
Pixels HD:1920X1080=2 megapixels
Lens 20X optical zoom f= 4.7 mm (WIDE) to 94.0 mm (TELE), F1.6 to F3.5
Min. illumination High sensitivity mode: 0.5 lx (IRC OFF)  0.095 lx(ICR On ) (F1.6,50 IRE)
Standard mode: 1.7 lx (IRC OFF) 0.3 lx(ICR On ) (F1.6,50 IRE)
BLC ON/OFF
WB Auto, Indoor, Outdoor, One-push, Manual
Interface
Voice talkback output 1 channel, MIC port(optional)
Audio output 1channel, linear output(optional)
Analog video output Support
Input alarm 1 channel
Output alarm 1 channel
Hard reset Support
Memory interface Support image and video storage, SD2.0,
Compression
Video compression H.264 Main Profile@Level 3.0 / MJPEG selectable
Resolution Master Streaming 1280*960,1-15fps/sec1280*720,1-25fps/sec
Second Streaming 640*480,1-25fps/sec
Video Bitrates 32Kbps~16Mbps settable
OSD Title  Support channel name, date and video information overlay; OSD position adjustable
Audio Compression G.726/G.711A/G.711U
Mask setting Max 4 Zones selectable
Dual stream Support
Email alarm Support
Protocol TCP/IP/UDP/RTP/RTSP/RTCP/HTTP/DNS/DDNS/DHCP/FTP/NTP/PPPOE/SMTP/UPN
ONVIF protocol Support
Motion detection Support intelligent mobile phone with Windows Mobile 6, Symbian V3/5 version , iPhone and Android system
Dome
Pan range 360° infinite continuous rotation
Tilt range 0°~90°  auto flip 180°
Manual Pan speed 0.1~250°/S
Manual Tilt speed 0.1~200°/S
Preset speed 120°/S
Preset accuracy ±0.20°
Preset Points 128

Intelligent power off real time memory

Power off memory of function set; automatic wakeup tour function
Operating temperature -30℃~60℃
Humidity 0%~90% (no-condensing)
Power 24VAC 3A 60Hz/50Hz
Consumption 40W (outdoor)
IR parameters
Infrared light High power LED
IR wavelength 850nm
Zoom angle Infrared angle and all-in-one synchronized variable angle can be 3.2°~60°
IR distance 150M
Flashlight No
Related validation IP66,CE,FCC,RoHs









Additional Information

Payment Terms T/T
Minimum Order 1
Lead Time / Delivery Time 5 Day(s)
Sample Available YES
Delivery Details Factory direct delivery
FOB Port Guangzhou
Loading Info Sea and air
Packing Info 5-7 working days 4pcs for one standard carton
Target Market(s) Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Mainland China, North America, Central & Southern Asia, Southeast Asia
