high efficiency solar PV system
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| Efficiency | 96%(Max) |
|---|---|
| Output Voltage | 220V±10 |
| Working Efficiency | >83% |
| Load Power | 2000W/3000W |
| Capacity | 20V/30A |
| Type | Off-Grid |
| Solar Power | 100W-300W |
| Application | Home |
Detail Description
| Modle No. | CN-GP1000 |
| Solar Panel | 200WP |
| Controller | Capacity:24V/30A Efficiency:96%(Max) Low-Voltage Protection:21±0.5VDC Stop Charging Voltage:30VDC Low-Voltage Self-Recovery:24±0.5VDC |
| Battery | Battery Type Deep Cycle Maintenace-free Lead-acid Battery Capacity 12V/100AH*2(Max:2400WH) |
| Inverter | Rated Output Power:2000W/3000W Working Efficiency:>83% Output Voltage:220V±10% Output Wave:Pure Sine Wave(THDI5%) Switching Time(ms):≤4ms(Switches between city power and inverter) Protection Function: 1.DC Over-Voltage Protection/Over-Voltage Self-Recovery 2.DC Low-Voltage Protection/Low-Voltage Self-Recovery 3.Over heat/Short Circuit/Overload Protection |
| Main Features | 1.AVR function:AC145V-275V(Input),AC198V-242V(Output) 2.Auto-switch,self-covery and unattended operation 3.Solar energy and untility power complementary functions: (1)The system can provide eletricity produced by solar energy to load directly.It can automatically select the solar energy or untility power as power source according to the change of sunshine,and the work mode will be chosen and swicthed automatically. (2)The system can automatically select the solar energy or untility power to charge the battery according to the state of the sunlight and battery voltage.AC bypass without charging is available. (3)The system can automatically identify the state of day and night,and interactive switches between AC mode and inverting mode at night. |
Power Consumption For Reference
| Appliance | Rated Power(W) | QTY(PCS) | Daily Working Time(H) | Daily Power Consumption(WH) |
| LED Lamps | 7 | 2 | 5 | 70 |
| Statellite receiver | 25 | 1 | 2 | 50 |
| LCD TV | 70 | 1 | 2 | 140 |
| Hair Dryer | 500 | 1 | 0.15 | 75 |
| LapTop | 90 | 1 | 2 | 180 |
| Other Devices | 10 | 1 | 2 | 20 |
| Total | 709W | 535 |
Electric Characteristics
Type |
We could offer on-grid system, off-grid system and portable solar system etc |
Output |
We could provide any watt as customer quested |
Use |
Widely used for electricity, industry, communication, navigation, irrigation, PV house and remote power requirements |
Design |
When we design solar system , need to know well the informations as following : 1.About load , is it DC or AC ? 2.What kinds of equipments do you want to use for solar system ? How many total voltage of load power ? 3.Do you want on-grid system or off-grid system please ? 4.How many hours of per day do you want to use for solar system please ? 5.How many constantly cloudy days do you need solar system work for ? 6.Where do you want to install solar system ? |
Note:
1.The System can work for2~3 constantly rainy days with these appliances.
2.Users can adjust loading devices and working time according to their demands.Longer working time is available by adding extra batteries and solar panel by users,the system has reserved the connetion port and capacity of solar controller.
Our company can desined according to customer\'s requirements.
Warmly welcome your inquiry!Thank you!
Additional Information
| Payment Terms | T/T, D/A, D/P, Western Union |
|---|---|
| Minimum Order | 5set/sets |
| Lead Time / Delivery Time | 15 Day(s) |
| Sample Available | YES |
| Delivery Details | small quantity delivery within 21 days,more than 21 days if big order. |
| FOB Port | Shenzhen |
| Loading Info | shipped by express,by sea or by air. |
| Packing Info | carton and pallet according to the specification of goods. |
| Target Market(s) | North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East |
