180pcs smd 12W LED Horizontal Insert Light

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Life	50,000 hours
Package	Yes
Tube Diameter	T8
Color Tones	Warm Color
Light Source Chip	SSC
Illuminant	SMD
Lamp Base	G12
Length	180cm
Voltage	220V
Power	12W

Detail Description

Product Type: 12W LED Horizontal Insert Light
Place of origin: China
Brand Name: Toplight
Model No.: TP-HI320-180-12W
FOB Port: Shenzhen port
Minimum Order: 30pieces
Payment Term: TT or Paypal
Shipping Term: by express, by air or by sea
Delivery Time: 4-7days for sample; 7-14days for bulk

Electrical parameters:
(1) electrical parameter:

Tube Length (mm)	Model No.	LED Quantity (pcs)	Luminous Flux (lm)	Socket
320mm	TP-HI320-180-12W	180pcs	1170-1440lm	2G11/G10Q Select

(2) basic parameter:

Power	12W
LED Quantity	180pcs 3528 LED
Input voltage	85-277VAC
Beam Angle	120degree
Power Factor	>0.85
Power Efficiency	>92%
Material	AL+PC

(3)PC and color temperature:

Color Temperature	Warm White(4000-4500K)
Natural White(6000-6500K)
Cool White(8000-16000K)
Tube PC	Clear PC
Frosted PC

Product Advantages:

1.It can replace the traditional 2G11 fluorescent with nice appearance.
2.The plug of the light can exchange G10Q with 2G11.
3.The products adopt the connection of AL and PC with inner driver and Aluminum PCB,it is better for heat sink.

Aging & Packaging:

Aging:
12W LED horizontal insert light\'s aging time is over 72hours, LED tube lights\' efficiency will improve better in the aging, and contribute to the efficiency of late use stability. LED in product quality control aging test is a very important link.

Package detail:

Tube Length	Model No.	Net Weight	Packing Size	Carton Quantity
320mm	TP-HI320-180-12W	0.24kg	710280240mm	50pcs/CTN

Structure installation

12W LED horizontal insert light could be installed on the the base lamp 2G11 or G10Q , pls take down the starter before installing.
Kindly Notice: before installing, please make sure the power source is off!
