10years experiences power supply with CE on EN61347 standard

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Color	black
Warranty	1year
OEM&ODM	welcome
Materials	ROHS&REACH
AC PLUG	US,AU,UK,EU
Output Frequency	50/60Hz
Output Current	2A
Input Voltage	220V
Output Power	1-50 W
Output Type	Single
Output Voltage	12V

Detail Description

10years experiences power supply with CE on EN61347 standard

Input Voltage：100~240Vac(Range:90~264Vac).
Input Current：0.7A max.
Frequency：50/60Hz(Frequency range:47~63Hz).
Output voltage：5.0-24V.
Output current：0-3A.
Ripple & Noise：150mV max
Power consumption at no load：0.3W max.
Conversion efficiency：〉75%
Voltage regulation/Load regulation：±5%
Hi-pot test： 3000 VAC/1min/5mA
Leakege current： 0.25mA max.@240 VAC
With Over-current,Over-voltage,Over-temperature, Short-circuit protection function
Operating temperature：0~40℃
Safety standard：UL/EN60950/GB4943
EMC standards：EN55022 class B/FCC Part 15 class B;EN55024/A1:2001/EN61000

Applications

Wireless communication electronics
Network hardware
Persional digitals
Audio&Video devices
Medical equipments
Appliances

MODEL NO	Input Voltage (Vac)	Input Frequency (Hz)	Output voltage (Vdc)	Output Current (A)	Certificate
KA24A-060YYYY	100-240(AC)	50/60 (Hz)	6.0(VDC)	0-3.2A	CE
KA24A-070YYYY	100-240(AC)	50/60 (Hz)	7.0(VDC)	0-3.0A	CE
KA24A-080YYYY	100-240(AC)	50/60 (Hz)	8.0(VDC)	0-2.8A	CE
KA24A-090YYYY	100-240(AC)	50/60 (Hz)	9.0(VDC)	0-2.5A	CE
KA24A-100YYYY	100-240(AC)	50/60 (Hz)	10.0(VDC)	0-2.4	CE
KA24A-110YYYY	100-240(AC)	50/60 (Hz)	11.0(VDC)	0-2.1A	CE
KA24A-120YYYY	100-240(AC)	50/60 (Hz)	12.0(VDC)	0-2A	CE
KA24A-130YYYY	100-240(AC)	50/60 (Hz)	13.0(VDC)	0-1.8A	CE
KA24A-140YYYY	100-240(AC)	50/60 (Hz)	14.0(VDC)	0-1.7A	CE
KA24A-150YYYY	100-240(AC)	50/60 (Hz)	15.0(VDC)	0-1.6A	CE
KA24A-160YYYY	100-240(AC)	50/60 (Hz)	16.0(VDC)	0-1.5A	CE
KA24A-170YYYY	100-240(AC)	50/60 (Hz)	17.0(VDC)	0-1.4A	CE
KA24A-180YYYY	100-240(AC)	50/60 (Hz)	18.0(VDC)	0-1.3A	CE
KA24A-190YYYY	100-240(AC)	50/60 (Hz)	19.0(VDC)	0-1.25A	CE
KA24A-200YYYY	100-240(AC)	50/60 (Hz)	20.0(VDC)	0-1.2A	CE
KA24A-210YYYY	100-240(AC)	50/60 (Hz)	21.0(VDC)	0-1.1A	CE
KA24A-220YYYY	100-240(AC)	50/60 (Hz)	22.0(VDC)	0-1.05A	CE
KA24A-230YYYY	100-240(AC)	50/60 (Hz)	23.0(VDC)	0-1A	CE
KA24A-240YYYY	100-240(AC)	50/60 (Hz)	24.0(VDC)	0-1A	CE

Type designation:KA24A-XXXYYYY series(\"XXX\" 042-240 digits representing the output voltage 4.2-24Vdc;\"YYYY\" 0-3000 digits representing the output current0A-3A)

As a leading manufacturer of switching power supplies,we supply AC/DC adapter,desktop power adapter, wall mount adapter, LED power supply, security power adapter, USB car charger, USB power adapter .

If you are interested in KY`s products,welcome to contact us for more details!

Contact name: Vicky Lan
Skype: colina2098
Mobile: +86-13824301593
Tel:+86-755-27826629 Ext:6013
Fax:+86-755-27827839
Website: www.kydy.cc

Additional Information

Payment Terms	L/C, T/T, D/P, Western Union
Minimum Order	1000
Lead Time / Delivery Time	20 Day(s)
Sample Available	YES
Delivery Details	20DAYS lead time upon receipt of your confirmation
Loading Info	By sea, by air, by express.According to clients requirements and clients\' customs policy.We guarantee to give the most economic and save delivery.
Packing Info	Inner packing: White box + Transparent poly bag. Outer packing: Carton 50pcs/carton in size 460420233mm
Target Market(s)	North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Middle East & South Asia, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East
