6.6lb Coffe Roaster/3kg Coffee Bean Roaster
- Payment Type:
- T/T
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Delivery Time:
- 30 Days
- Transportation:
- Ocean, Land
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|---|
| Productivity: | 100pcs/year |
| Supply Ability: | 100pcs/year |
| Payment Type: | T/T |
| Certificate: | CE ROHS IEC |
| Transportation: | Ocean,Land |
Product Description
Product Description
| NC-003 3kg Gas Coffee Roaster Parameters | |
| Roaster Dimensions: | 47.2×39.4×50 in (1200×1000×1270mm) |
| Roaster Weight: | 330.1lb (150kg) |
| Chaff Collector Dimension: | 15.7×59.1 in(400×1500mm) |
| Chaff Collector Weight: | 66.1lb (30kg) |
| Net/Gross Weight: | 396.9/485lb (180/220kg) |
| Crate Dimension(One Crate): | 66.9×51.2×57.1lb (1700×1300×1450mm) |
| Drum Thickness: | 0.2 in (4mm) |
| Drum Diameter/Length: | 10.2/13.8 in (260/350 mm) |
| Drum Construction: | 430 stainless steel, welded |
| Cooling Tray Diameter: | 15.7 in (400mm) |
| Cooling Tray Stirring Arm Length: | 11.8 in (300mm) |
| Average Roasting Time: | 15 minutes batch |
| Production: | 26.5lb/hr,211.6lb/day (12kg/h, 96kg/day) |
| Roaster Voltage/Frequency: | Single phase 220v,15 amp service 50-60Hz |
| Step-up Transformer: | 120v to 220v, 1000 watt |
| Drum Motor | 200w |
| Exhaust Fan Motor: | 400w |
| Exhaust Fan Max. Airflow: | 130m³/h |
| Cooling Fan Motor: | 200w |
| Cooling Tray Stirring Motor: | 100w |
| Heating Mode: | Natural Gas or Propane |
| Max. BTU: | 40,000 |
| Burner Control: | Ball Valve |
| Gas Connection: | 3/8'' NPT |
| Typ. Chaff Collector Exhaust Temp: | 300F(during normal use) |
| Recommended Temp Controller Limit: | 455F (about 30 seconds into rolling second crack) |
| Max. Gas Usage | 1.3lb/hr (0.6kg/h) |
| USB Logging Interface: | Phidget 1048 |
| Logging Thermocouples: | BT,ET, incoming air |
