Indoor P5 LED display
- Payment Type:
- T/T
- Incoterm:
- FOB
- Delivery Time:
- 15 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Payment Type: | T/T |
| Incoterm: | FOB |
.High refreshing rate
2.Super uniformity in color
3.Energy-saving,reducing power consumption
4.Single dot-calibration
|
|
|
|
Pitch(mm) |
5 |
|
Density (pixel/m2) |
40000 |
|
LED |
SMD 3in1 |
|
Pixel configuration |
1R1G1B |
|
Size of module (L×H) |
320×320mm |
|
Module resolution (L×H) |
64×64 |
|
Weight/module(g) |
300 |
|
Cabinet size (mm) |
640×640×80 |
|
Brightness(cd/ m2) |
≥1000 |
|
Power consumption /module |
Max:18W Avg:6W |
|
Power consumption (w/ m2) |
Max:700W Avg:230W |
|
View angle |
H120°/V120° |
|
Drive IC |
PWM IC |
|
Processing |
12 bit/R,G,B |
|
Greys scale |
65536 grade/R,G,B |
|
Frame rate |
≥60 Hz |
|
Refresh rate |
≥800 Hz |
|
Color temperature |
3200K-9300K |
|
Operating voltage |
AC220V/50HZ AC110V/60HZ |
|
Lifetime |
50000h |
|
Dead dot |
<1/10000 |
|
Working condition |
Temperature -20°C~+40°C; Humidity 10%~90% |
1. HIGH REFRESH RATE
This product use PWM high-end constant drive IC. The refresh rate of the display can reach 1920 Hz in the condition of single card loading, without losing gray scale, keep the image smooth and no scanning beam, which can meet the requirement of high-end applying for stage performance and rebroadcast etc.
2. ENERGY SAVING AND ENVIRONMENTAL PROTECTION
Special design of circuit diagram and high-end drive IC can help to much improve the brightness of the display. On the assumption of suitable brightness and display property, the power consumption is much lower than the like products on the market, it can save electricity over 50%.
3. FLAT SCREEN, NO GAP
Thanks to our patent bottom holder, we can connect the panels together without taking any of the auxiliary structures. The panels were made by high-precision molding plastic injection which ensure no slit on the screen and the panel surface looks quite flat.
4. WIDE-viewing angle
The cover was fixed from the back and no screws could be seen on the front side, so the surface integrity of the screen is good and no bright spot would appear caused from light leak of the screws.
The depth of the cover is no less then the height of LED lamps, there won`t be shadow or dark space on the screen under any degree of angle.
