Surface Light Wave, 21.5 Inch And 10 Points Multi Touch Lcd Monitor For Business Demo
Your message must be between 20 to 2000 characters
Contact NowSurface light wave, 21.5 inch and 10 points multi touch LCD monitor for business demo
Hitouch Surface Light Wave 21.5’’ 10 Points Multi Touch Monitor HT-LED21S is a kind of touch screen display which is widely used in multi areas including Education, multimedia, advertising, exhibition display, business etc. We combine the surface light wave multi touch screen with HD display, make the display to an interactive display.
Surface Light Wave 21.5’’ 10 Points Multi Touch Monitor Main Features:
1.2 In One
Touch screen +LED play 2 in one machine, with PC, it can completely replace the projector+IWB+Laptop in the meeting system/teaching system
2.High Integration, easy operation
3.Integrates perfectly with surface light wave touch screen, and digital HDTV display, you may operate on the screen with windows program, teaching, drawing, editting documents etc.
4.Multi touch operation, no need special pen, any opaque obejcts and fingers can write on the screen with windows system
5.Various application Field such as interactive education, business illustration, military
6.Multi touch technology
7.High definition, contrast, resolution
Specifications:
Hitouch Surface Light Wave 21.5’’ 10 Points Multi Touch Monitor Spec |
||
Touch Screen Part |
Technology |
Surface Light Wave |
Touch Accuracy |
±1mm, over 90% in sensitive touch area,resolution reported by USB is: 32767*32767 |
|
Response Speed |
≤6ms |
|
Touch Object |
Finger, glove hand, or other opaque object |
|
Touch Points |
10 points touch at the same time |
|
Touch time |
No limited |
|
Scan Speed |
100fps |
|
sampling rate |
60ppi/s |
|
Touch pressure |
No |
|
Min recognition objects |
3mm*3mm, support super slim pen point touch |
|
Working voltage |
3.3V-5.0V |
|
Average current |
Less than 100mA |
|
Anti-highlight |
Yes |
|
SDK Software Language |
C/C++,C#/.Net,Flash/Flex/ AIR,Flash(AS 3.0),WPF, Java |
|
Sleeping mode |
Support (when there is no touch the touch screen will enter sleeping mode) |
|
Surface durability |
Hardness of glass is level 7 |
|
Operating system |
Win/XP/Win7/win8/Mac |
|
Display Part |
Touch Screen Size |
21.5’’ |
Physical resolution |
1920 (Horizontal)×1080 (Vertical) |
|
Angle |
178° |
|
Circumstance
|
Operating Tempareture: 0℃~40℃ |
|
Operating Humidity: 10%~80% |
||
Storage Temparature: -20℃~40℃ |
||
Storage Humidity: 5%~95% |
||
Installing Methods |
Table putting |
|
Input Voltage |
AC 110-240V 60/50HZ |
|
Power |
100V-240V |
|
Color |
Black or White |
Competitive Advantage of Surface Light Wave 21.5’’ 10 Points Multi Touch Monitor :
1) Perfect proformance of the touch screen
Surface Light Wave 21.5’’ 10 Points Multi Touch Monitor is made with surface light wave touch screen, new touch screen technology.
SLW touch screen: The lines will never cross each other where there are multi people drawing at the same time
If use others touch screen, the lines will cross much, very bad performance
2) Wider application circumstance
Surface light wave touch screen is Anti-interference.
Others technology touch frame can not adapt to strength light environments. Surface Light Wave uses a new anti-jamming technology.It can adapt strength light environments.
3) Better Resolution.
Surface Light Wave Physical resolution is 1000*1000.reporting resolution is 32767*32767.can distinguish minor jitter.
4) More options
Surface light wave can come with differenct multi touch points up to 32 points according to difference clients' requirements, they are both performs very good on the touch response and touch speed.
Others technology multi touch can not performs well especially multi people operating the screen, there are drifts, direction disturb problem.
5) Easier after-sales
Since the SLW touch screen is made with more intensive sensors and more advanced design, the multi touch will still work even there are 10% sensors broken.
While others technology for example IR touch screen, once there is broken sensors, the touch will not work properly, even whole area can not work.
6) Good design appearance
Surface Light Wave 21.5’’ 10 Points Multi Touch Monitor has a good look on its apperance, also have white and black color for choice.
7) Touch screen LED 2 in one
Surface Light Wave 21.5’’ 10 Points Multi Touch Monitor is touch screen LED 2 in one, it integrate the multi touch screen and Full HD LED display all together,it gains the cost performance of the product, and make it more steady when working.
