Mini PC box, high performance HT7000 for interactive teaching system

Hitouch HT7000 is a mini PC box which is using for projects, it has stable performance especially under the long-working condition. It can work 7 days 24 hours continuously. Different CPU (i3/i5/i7) optional.

Applications

1. Education: interactive classroom teaching

2. Business meeting: interactive demostrate

3. Enerprise traning, research project

4. Interact media, entertainment

Specifications

CPU	Socket P Support Intel Core 2 Duo and Celeron CPU, FSB 667/800/1066 MHz (TDP≤35W)
Chips Group	NVIDIA MCP7A-LP Chip
RAM	Dual Channel Mode SO-DIMM DDRIIIx 2, 800/1066/1333 MHz Max support 8GB
Graphic Chip	Integrated Graphics GeForce 9300
Expansion Slot	Mini Card Slot x 1, USB mini card bridge board x1 (option)
Sound Chip	Realtek HD AUDIO CODEC ALC662
Internet Chip	Realtek 10/100/1000 Mbps LAN Controller
Front Panel Input/Output	Power Button x 1, HDD/Power indicator (blue) x1, USB 2.0 Port x2
Back Panel Input/Output	DC 20V Jack x1, HDMI Port x1, D-Sub VGA Port x 1, RJ45 LAN Jack x1, USB 2.0 Port x4, RS232 Serial Port x1, HD Audio ports (speaker out x1, Mic in x1, Line in x1)
Power	90W (20V, 4.5A) AC power supply
Voltage	AC100-240V
Product size
Housing	SECC metal housing
Size	16.416.64.8CM
Wight	1.145KG (not including CPU, HDD & RAM)
Operating Circumstance
Operating Temperature	Operating: 0℃-45℃; Storage: -30℃-60℃
Operating Humidity	90% RH (40℃non-condensing)
