Basic Info

Product Description

Calibrated Brightness(cd/sqm,nit):	8500 Nits(adjustable)	Pixel Configuration:	DIP346 1R1G1B
Pixel Density(dots/sqm):	6944 Dots/sqm	Pixel Pitch(mm):	12mm
Refresh Rate(Hz):	>1200 Hz	Average Power Consumption:	450 W/sqm
Control Mode:	Synchronous Or Asynchronous	Display Function:	Video
LED Drive:	Constant-current	Screen Operation Mode(scan/static):	1/4
Tube Chip Color:	Full Color	Usage:	P12 Outdoor LED Display Screen
View Angle(degree)(50% Brightness):	V60/H120	Scan Driver:	1/4 Scan

Full Color P12 Outdoor LED Billboard Digital Signage for Shopping Center DIP346 1R1G1B

Quick Detail:

1) Stable quality:Opto + Silan chipset;

2) High brightness:>6500 nits;

3) Scan driver:1/4 current;

4) Module size(L*W):192*192mm;

Description:

P12 Outdoor Full Color LED Display Screen

12mm pixel pitch,1R1G1B,6944 dots/sqm,P12 Outdoor Full Color LED Display Screen creates high brightness and energy saving,display variable video resources,animations,messages to attract attention. We can see P12 Outdoor Full Color LED Display Screen in many occasions,like sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc

Applications Occasions:

Sports,advertising,traffic,entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc

Specifications:

P12 Outdoor Full Color LED Display Screen

Pixel configuration	DIP346 1R1G1B
LEDs configuration	Red:wave length: 625~630nm;1100-1300mcd Green:wave length: 525~530nm;1900-2400mcd Blue:wave length: 470~475nm;500-700mcd
Pixel pitch(mm)	12
Pixel density(dots/sqm)	6944
Calibrated brightness(cd/sqm,nit)	8500 nits(adjustable)
Calibrated brightness proportion ratio	R:G:B=3:6:1
Contrast ratio	4,500:1
Brightness adjustment(dimming)	100 grade auto/manual-adjustment
View angle(degree)(50% brightness)	V60/H120
Color capability	4.4 trillion
Refresh rate(Hz)	>1200 Hz
Frame frequency(Hz)	>60 Hz
Interface port	DVI interface(DVI connector)
Input signal	VGA, Video, AVI, MOV, MPG, DAT, VOB etc.
Protection grade	IP65 front side/IP43 back side
LED Drive	Constant-current
Lifetime(hours)(50% brightness)	100,000 hours
Signal transmission direction	Horizontal
Operating temperature(Celsius degree)	-30 ~ 65
Storage temperature(Celsius degree)	-35 ~70
Operation humidity(RH)	0-95%
Operation humidity(RH)	0-99%
Service	Front and back service optional
Control mode	Synchronous & asynchronous available
Communication options	Wire Ethernet, Fiber Ethernet,RF wireless,GPRS
Power	120/240 VAC single phase(50-60Hz)
Maximum power consumption(W/sqm)	900
Average power consumption(W/sqm)	450
Screen operation mode(scan/static)	1/4
Module configuration(Pixels quantities of the module)	Length	16
	Height	16
Module dimensions(mm)	Length	192
	Height	192
Cabinet configuration	Length	80
	Height	80
Cabinet dimensions(mm)	Length	960
	Height	960
	Width	120 (+30~35mm module)
Aspect Ratio(L:H)	4:3 or 16:9
Packaging configuration	1~4 standard cabinets in a packing case
Packing material	Wooden case/carton/flight case(optional)
Packing weight(KG)	net	50KG/m2
	gross	55KG/m2
