Basic Info

Product Description

LED Packing:	DIP	Pixel Configuration:	DIP1R1G1B
Pixel Density(dots/sqm):	27778	Pixel Pitch(mm):	6
Average Power Consumption:	650W/M2	Communication Options:	Wire Ethernet, Fiber Ethernet,RF Wireless,GPRS
Control Mode:	Synchronous Or Asynchronous	Display Function:	Video
LED Drive:	Constant-current	Refresh Rate(Hz):	≥600 Hz/S
Scan Driver:	1/4 Scan	Screen Dimension:	Custom
Screen Operation Mode(scan/static):	1/4	Tube Chip Color:	Full Color
Usage:	Outdoor Advertising	View Angle(degree)(50% Brightness):	V60/H120

DIP236 Outdoor Full Color LED Display Billboard , High Definition P6 LED Screen

Quick Detail:

1) Stable quality:Opto + Silan chipset;

2) High brightness:>11000 nits;

3) Scan driver:1/4 current;

4) Module size(L*W):192*192mm;

Description:

P6 DIP Outdoor Full Color LED Display Screen

6mm pixel pitch,1R1G1B,27778 dots/sqm,P6 DIP Outdoor Full Color LED Display Screen creates high brightness and energy saving,display variable video resources,animations,messages to attract attention. We can see P6 DIP Outdoor Full Color LED Display Screen in many occasions,like Sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc

Applications Occasions:

Sports,advertising,traffic,entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc

Specifications:

P6mm P7mm P8mm P10mm DIP Outdoor LED Display Screen:

Module	Pitch/mm	P6	P7	P8	P10
	Module size/mm	192*192	224*112	256*128	320*160
	Density of pixel/(dots/m2)	27778	20408	15625	10000
	Pixel composition	1R1G1B	1R1G1B	1R1G1B	1R1G1B
	Led encapsulation	DIP	DIP	DIP	DIP
	Resolution of module	32*32	32*16	32*16	32*16
Main	Optimum viewing distance	≥5	≥6	≥7	≥8
	View angle / °	V60/H120	V60/H120	V60/H120	V60/H120
	Average power consumption/W/M2	650	600	550	500
	Max power consumption/W/M2	1300	1200	1100	1000
	Size of cabinet/mm	768*768	896*672	768*768	1280*960
	Resolution of cabinet	128*128	128*96	96*96	128*96
	Frame frequency / Hz/S	≥60	≥60	≥60	≥60
	Refresh rate Hz/S	≥600	≥600	≥600	≥600
	Luminance of white balance	≥11000nits	≥10000nits	≥8000nits	≥8000nits
	Weight of cabinet/kg/sqm	55
	Driving method	1/4 scan constant current
	Operation of Environmental Temperature/°C	below 30 to above 65
	IP rating	Front,IP65;Rear,IP43
	Working vlotage	110-220 VAC/+/- 10%
	Grey scale/color	displaying colors≥16.7M(synchronized)
	Brightness adjustment	256 levels of each color(manually),100 levels of each color(automatically)
	Input signal	RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
	Control system	linsn(sending card,receiving cards and Hubs)
	Average of non-failure life	>50,00h
	Life span	>100,000h
	Functionaless dot rate	<0.0001
