Square High Power Smd Led Module 1.5w Ip68 Injection And Waterproof With 4 Chips

Square High Power Smd Led Module 1.5w Ip68 Injection And Waterproof With 4 Chips

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Dimension:	35(l)35(W)4(H)mm	LED No:	5 Pcs 5050 SMD LED Beam Angle 150Degree
Voltage:	Input DC12V	IP:	IP68 The PCB Be Covered By Resin
Net Weight(g):	10g/pc.200g/20pcs	Color:	White

Square High Power SMD LED Module 1.5W IP68 Injection and Waterproof with 4 Chips

Lowest Price Injection Waterproof RGB LED Module 5050

New injection design 60lm ,3 SMD5050 Epistar,waterproof RoHS CE injection 5050 led module

dc12v 1.5W ABS injection smd 5630 led module

outdoor advertising waterproof smd led module 5050 with 4 chip, single color for acrylic led backlit sign,100lm

4pcs 5050 SMD LED module,20pcs a string RGB,12V led pixel module

Application:

1. Electronic signs Backlighting for Advertisement

2. Commercial advertising signs

3. Channel letters Message display backlighting

4. LED light strips Signboard and Billboard

5. Automotive lighting

6. Festival decoration

7. Advertisement light-box

8. Accent lighting Logo backlighting

Specification

Dimension	35(l)35(W)4(H)mm
LED No	5 pcs 5050 SMD LED Beam angle 150Degree
Voltage	Input DC12V
Current	30mA	30mA	30mA	30mA	30mA
Watts	0.48	0.48	0.48	0.72	0.72
Lumen	18~28	18~28	18~28	16~22	16~22
Color	White	Blue	Green	Yellow	Red
IP	IP68 The PCB be covered by resin.
Net Weight(g)	10g/pc.200g/20pcs
Part No	REX35-5W 5050	REX35-5B 5050	REX35-5G 5050	REX35-5Y 5050	REX35-5R 5050

Item Number: REX35-4X(X-White/red/blue/green/yellow)

Judged against the performance of standard neon or fluorescent lamps, REXLEDs 4 SMD LEDs Waterproof LED Modules (REX35-4X3528 Series) are ideal for signage channel letters’ compacts spaces, which provide significant energy cost reductions(less 40%than neon), easier jobsite installation(splice connector or twist-on wire connector and 3M double-faced sticking tape), free maintenance and more consistent brightness

Features

·High Brightness

REXLEDs 4 SMD LEDs waterproof Module adopts 4pcs 3-chip SMD LEDs as its luminous body in high intensity and can emit higher brightness at lower cost. Bigger chip in LED. No spot. No shadow

·Excellent heat dissipation

REXLEDs 4 SMD LEDs waterproof Module house inside aluminum crust with excellent heat dissipation.

·Easy Installation

REXLEDs 4 SMD LEDs waterproof Module can be easily installe with 3M double-sided sticking tape and connectors.

·Extended Life

With little heat, proper drive characteristics and high quality LEDs, REXLEDs 4 SMD LEDs waterproof Module have a life time of more than 50, 000 hours.

·Totally waterproof

With IP68 protection degree, REXLEDs 4 SMD LEDs waterproof Module can operate normally in cloudy, rainy, desert, and snowy weather conditions and pool. The SMD LEDs are totally covered by resin.

·Friendly environment

Pb free. With CE/RoHS/SGS certificate, REXLEDs 4 SMD LEDs waterproof Modules are up to 60% more energy efficient than neon.

·Safe Application

Low voltage DC12V, safety and stable. Free maintenance
