Hot Sale 2.4ghz Wireless Av Sender With Ir Extender
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
product name: hot sale 2.4GHz Wireless AV sender with IR extender
Specification:
1. 2.4GHz wireless technology delivers audio and up to 60m(clear path) Ultra compact design.
2. Integrated omni directional antenna
3. Infra-red extender cable transmit with 3 miniature infra-red eyes signals to 3 different pieces of AV equipments
3. CE marked, R&TTE EMC and LVD approved
4. 4 Switchable frequencies for best signal transmission and reception
5. PLL frequency synthesizer for enhanced sound/picture quality
Hot sale 2.4 GHz wireless AV sender with IR extender
With 4 selectable channels(Dip Switch)
* Transmit the crisp A/V signal with radio frequency
Specification:
| ITEM | 201T | 201R | ||||
| 2.4GHz antenna | Internal Omni-directional antenna | Internal Omni-directional antenna | ||||
| 433MHz antenna | External omni-directional antenna | External Omni-directional antenna | ||||
| Transmit power | 10 dBm(Typical) | – | ||||
| Sensitivity | – | –85dBm type | ||||
| Frequency band | 2.400~2.4835GHz | 2.400~2.4835GHz | ||||
| Channel Customer | 4 selectable channels 2414, 2432, 2450, 2468 MHz |
4 selectable channels 2414, 2432, 2450, 2468 MHz |
||||
| Input format | Available in NTSC or PAL | – | ||||
| Output format | – | Available in NTSC or PAL | ||||
| Video input level | 1 Vp-p@75Ω | – | ||||
| Audio input level | 1 Vp-p@600Ω | – | ||||
| Video output level | – | 1 Vp-p@75Ω | ||||
| Audio output level | – | 1 Vp-p@600Ω | ||||
| Input / output Connector | MINI 6 DIN | MINI 6 DIN | ||||
| Operating condition | Indoor usage recommend | Indoor usage recommend | ||||
| Remote control frequency | 433.92MHz | 433.92MHz | ||||
| IR carrier frequency | 32~38KHz | 32~38KHz | ||||
| Power Consumption | 12Volt DC, 500mA(Typical) | 12Volt DC, 500mA(Typical) | ||||
| Operating Temperature | -10℃ ~ +60℃ | -10℃ ~ +60℃ | ||||
| Dimension/Weight | 22*16*9 cm / 0.94 KG | |||||
| Carton Size/ Quantity | 45*38*33 cm / 15 PCS | |||||
1. 2.4GHz wireless technology delivers audio and up to 60m(clear path) Ultra compact design.
2. Integrated omni directional antenna
3. Infra-red extender cable transmit with 3 miniature infra-red eyes signals to 3 different pieces of AV equipments
3. CE marked, R&TTE EMC and LVD approved
4. 4 Switchable frequencies for best signal transmission and reception
5. PLL frequency synthesizer for enhanced sound/picture quality
Hot sale 2.4 GHz wireless AV sender with IR extender
With 4 selectable channels(Dip Switch)
* Transmit the crisp A/V signal with radio frequency
* Compact size
* With 2.4 GHz antennas embedded into housing
* Remote control the A/V source with IR extender
* NTSC/PAL video format available
* Compatible with Camcorder or CMOS camera application
