30w Led Flood Lamp 30w Led Flood Light With Ul Listed Led Driver
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Advantages: 30W NEW module LED luminaire
Technical parameters of the 30W NEW LED floodlamp
Photos of IP65 outdoor LED flood light 30W
30W floodlight distribution curve diagram:
30W flood lamp Average Flux Diagram:
High Power Floodlight Appliaction Photo
Our Service:
We commit to our 24 hour response time on all of your inquiries on any kinds LED flood light 10W ~ 300W. If we have your answer on hand, we respond immediately with all specifics required. We pride ourselves on minimizing uncertainty:
• Speedy and efficient responses
• Clarity, getting it right
• Dependable quality
• Competitive price & Advantages
• Efficient and timely delivery
You're welcome to contact with our experienced and efficient team for any your outdoor floodlight solution.
1. Die-cast floodlight. The original heat sink owns a patent. It is hollowed at the top and bottom of the heat sink , which is conducive to heat convection.
2. The light source input line and the power supply output line connect through a butt plug. All parts of the lamp can be easily assembled and disassembled respectively. Could be easy maintenance.
3. Attractive apperance, using Philips LED that's more 120LM/W, Meanwell LED Power Supply.2. The light source input line and the power supply output line connect through a butt plug. All parts of the lamp can be easily assembled and disassembled respectively. Could be easy maintenance.
Technical parameters of the 30W NEW LED floodlamp
| Alightek CHINA 30W LED floodlight module | ||
| 1 | Model Number | AL-NFL01W30 |
| 2 | Consumed Power | 33W ± 3W |
| 3 | LED driver | Meanwell |
| 4 | Input voltage | AC90-295V |
| 5 | Input frequency | 50 ~ 60HZ |
| 6 | Power factor | >0.9 |
| 7 | LED quantity | 15pcs |
| 8 | LED type | Philips Rebel ES |
| 9 | Luminous flux | 2900-3060lm |
| 10 | Light efficacy | >80lm/W |
| 11 | Color tempreture | 3000-7000K |
| 12 | Color rendering index | Ra:70-80 |
| 13 | LED angle | 30/60/85*135/ 60*135 |
| 14 | Shape | Rectangle |
| 15 | Material | aluminium alloy |
| 16 | Housing color | aluminiumGrey/Black/White |
| 17 | Dimension | 172x218×49mm |
| 18 | Net weight | 3.2KGS/set |
| 19 | Gross weight | 3.6KGS/set |
| 20 | Working tempreture | -20 to +50°C |
| 21 | Lifespan | >50000hours |
| 22 | Warranty | 3 years |
| 23 | Certification | CE and RoHS compliant |
Photos of IP65 outdoor LED flood light 30W
30W floodlight distribution curve diagram:
30W flood lamp Average Flux Diagram:
High Power Floodlight Appliaction Photo
Our Service:
We commit to our 24 hour response time on all of your inquiries on any kinds LED flood light 10W ~ 300W. If we have your answer on hand, we respond immediately with all specifics required. We pride ourselves on minimizing uncertainty:
• Speedy and efficient responses
• Clarity, getting it right
• Dependable quality
• Competitive price & Advantages
• Efficient and timely delivery
You're welcome to contact with our experienced and efficient team for any your outdoor floodlight solution.
