Crystal Clock Oscillator At-26 6.0 ~ 60 Mhz

Ultra small SMD type
High precision characteristics
covering up to high frequency range
Automatic mounting

ClockOscillators:
A crystal oscillator, which consists of a crystal units and an inverting amplifier, outputs a stable frequency when subjected to a specific voltage. Crystal oscillators are employeed as a simple means of providing clock generators used for information processing in office automation and other electronic equipment.

crystal clock oscillator   AT-26 6.0 ~ 60 MHz

quartz crystal oscillator AT-26 6.0~ 60 MHz

Frequency Range: 6.0 ~ 60 MHz

Frequency Tolerance (at 25 oC):  ± 30 ppm, or specify

Frequency Stability Over Operating Temperature Range:  ± 30 ppm, or specify

Operating Temperature Range: - 20 ~ +70 oC, or specify

Shunt Capacitance (C0): 7 pF Max.

Drive Level: 1 ~ 500 μW (100 μW typical)

Load Capacitance: Series, 16 pF, 20 pF, 30 pF, 32 pF, or specify

Aging (at 25 oC) : ± 3 ppm / year Max

Storage Temperature Range: - 40 ~ + 85

crystal clock oscillator   AT-26 6.0 ~ 60 MHz
