Lcd Ptz 3d Key Board

2.5 inch high-definition TFT LCD LCD screen, can display the image of the front camera to real-time;

TFT video playback, a video input;

Three-dimensional joystick control, convenient control, flexible;

English editor in OSD menu, adjustable settings of various communication parameters, simple operation;

Automatic adaptation of NTSC /PAL system image, without the need for manual setting;

Support RS485/RS232/RS422 communication interface control mode;

Design of USB data interface;

Support for PELCO-P, PELCO-D and other protocols;

Function shortcut custom functions, through the keyboard function menu custom shortcut keys, more humane;

Technical parameters:

Power supply DC9V~12V, 1A

Power 5W

A 2.5 inch display high-definition TFT LCD LCD

Video input BNC

Video signal format for NTSC/PAL ( automatic adaptation)

The video standard of 1± 0.2Vp-p, 75.

The communication interface of RS485 ( half duplex) /RS422 ( full duplex )

RS232 interface, DB9 base

The USB interface, receive, send data rates up to 300K Byte/s

A variety of communication protocol control protocol PELCO-D, PELCO-P etc.

The communication baud rate 2400bps, 4800bps, 9600bps, 19200bps

Address 1 ~ 255 address is optional

Control left / right; on / off

Iris: on / off

Focus: the near / far

Zoom: push far / near

Deposit / adjustable preset, cruise scanning, scan pattern, horizontal automatic scanning, guarding position

Three-dimensional ( left / right operating rod; the upper / lower; zoom )

The working temperature of 0° ~ 50 °

Dimension L290mm*W221mm*H79mm
