polyimide copper flexible pcb

1) Min. Trace width: 0.05 mm
2) Min. Space between trace: 0.07 mm
3) Min. Hole size: 0.1mm
4) Thickness tolerance:
A) Single sided: 0.005"
B) Double sided: 0.010"
5) Base materials: Polyimide and polyester
6) Conductor (copper thickness): 13um~105um. (RA and ED copper)
7) Cover-layer: Polyimide and polyester (solder mask printing is available)
8) Adhesive material: Epoxy, acrylic and polyester
9) Stiffener materials: FR-4, mylar and polyimide
10) Surface finishes: ENIG,Plated gold ,OSP

PCB manufacturing capacity

Material

FCCL

Tai-flex,Dupont

/

FCCL

Ad PI,Adhesive less PI,Halogen free PI

/

THK of FCCLPI

0.5,1,2mil

/

Cu THK of FCCL

0.5,1mil

/

THK of CVL

0.5,1,2mil

/

PI Stiffener

3,5mil

/

THK of AD

25um,40um

/

No-flew pp

Arlon1080 (49N,38N);

Dim:18X24Inch

/

FR-4

7628/2116/1080

/

Cooper foil

ED:12,18,35,70;RA:70um

/

AD.

25um,40um

/

CVL

PI THK:0.5,1,2,3mil

/

Surface Treatment

Plating Gold(Hard gold)

0.25-0.76um, Plating Gold:>0.76um( )

/

ENIG

Ni thk:3--8um,Gold THK:0.025--0.1um

/

Soft Gold

Ni thk:3--8um, Gold THK:0.025--0.13um

/

Immersion Tin

Tin THK:0.80-1.20um

/

Immersion Silver

Silver THK:0.10-0.30um

/

0SP

Film THK:0.15-0.30um

/

HAL,

Tin THK:2-40um

/

HAL lead free

Tin THK:2-40um

/

Silver slurry

Silver slurry taphole≤0.3mm,THK≥0.3mm; 2 .Silver slurry THK: 10-25um; 3. Min gap between Silver slurry & conductor:15MIL;

/

Selective surface finishing

Flash gold+gold finger,ENIG+OSP,ENIG+GOLD Finger,ENIG+HAL,Flash gold+HASL, Immersion sliver+gold finger, immersion Tin+gold finger,Silver slurry+Plating gold,,OSP+ Plating Gold Finger,Silver slurry+ENIG

/

Product Type

Buried /blind via FPC

Uncross Buried /blind via FPC

/

Ladder Fab

Inner-L exposure PTH or dis between Pad to O-L circ≥15MIL

/

Stress AD.

Stress AD W.:2mm;Type :3M

/

Impedance Control

Odd,Difference,tolerance±15%

/

Rigid-flex with bot.&top Flex

Slot W.≥5mm

/

Flex Unclad Fab

without exposed PTH or pad

with exposed PTH & pad

Flex Unclad Fab

without exposed PTH or pad

with exposed PTH & pad

Selective hollow FPC

1-L:finger length≤5mm;Line W≥10mil;

/

PCB Superiority

1.High efficiency&Experience

We can provide one stop service.Established in 1998, with many years hard-working and constant innovation,we have

grown up into a professional PCB&PCBA manufacturer. We have our own independent research and development

department and sophisticated quality control system.

--------------------------------------------------------------------------------

2.Quality

Our product are manufactured according to the UL/Rohs standards to insure quality assemblies from start to finish. Whether

it's a simple custom or not.Product or a complex turnkey production run, We will adhere to the highest quality standards.

--------------------------------------------------------------------------------

3.Protecting your interests
Protecting your Intellectual Property is job one! Our staff of trained professionals are all working under a strict confidentiality

contract and treat your important documentation as they would their own.

--------------------------------------------------------------------------------

4.Service

We can provide 24hours service for you. We pride ourselves on our ability to custom tailor programs around our customers'

needs.We take time to listen to your unique business needs and then set out to surpass them.

PCB Quotation Need

A. PCB GERBER file and specification .

B. Your special requirementsfor the PCB Board.

C. Your testing instructions if you wanna test.

Delivery method

1. By DHL, UPS, FedEx, TNT etc.

2. By EMS (Usually for Russia Clients), price is high.

3. By sea for mass quantity according to customer's requirement.

4. By customer's Forwarder

5. payment prefer -- T/T, Western Union ( HSBC )

polyimide copper flexible pcb

Application

Products are applied to a wide range of High-tech industries such as: LED, telecommunication, computer application, lighting, game machine, industrial control, power, automobile and high-end consumer electronics, ect.
By unremitting work and effort to the marketing, products exports to American, Canada, Europe counties, Africa and other Asia-pacific countries

Polular 1~18 layer multulayer FR4 PCB tv motherboard

POLYIMIDE COPPER FLEXIBLE PCB
