We offer:PCB,PCBA,Singe-side PCB,Double-side PCB, Multilayer PCB,Aluminium PCB,Spray Tin PCB,Immersed Gold PCB,HDI Mobilephone PCB,Gold-plating PCB,(printed circuit board with assembly)PCBA,SMT PCBA,DIP PCBA,PCB&PCBA Copy,PCB Assembly,OSP,HASL and so on

PCB&PCBA information:

*Base material: FR4, TG, CEM-1, Aluminium
*Copper thickness: 0.5-2.0 oz
*Thickness: 0.2-3.0mm
*Solder mask: green, red, blue, yellow, black, white etc
*Min. line width: 0.2mm
*Min. line space: 0.2mm
*Min. hole diameter: 0.25mm
*Max board size : 600 x 1200mm
*Surface treatment: ,spray tin,HASL, lead free, immersion gold,Gold-plate, OSP, ENIG etc
*lead time: seven days
*Capability:30,000 Square Meter/Square Meters / Month

PCBA (printed circuit board with assembly)
a)Being a PCB producer, we always have a very close relationship with the design
b)As a result, we are in a very good position in supplying not just PCB , but also assembly the
whole product for you
c)Instead of sourcing separate producer for PCB and assembly, it is better to choose a
manufacturer that can do both things.
d)We always do our best price best quanlity and best service in PCB and PCBA for you well and high quality control.

We provide one-stop service from PCB to PCBA, Quick-turn prototypes to mass production
For pcb,we can make 1-12layers at very competitive price , small order acceptable
Wish good quality, on time delivery and perfect service should be the reason you choose us as a pcb &pcba supplier in China.

Specifications:

Print circuit board design and assembly

Single layer and multiple layers board

All size and shape can be made With ISO9001/UL/RoHS marks

Small quantity are accepted

Fine quality and cheap price

Strict quality system

High quality circuit board

Quick turn Strong engineering support

Product lines:

-Rigid PCB( Single-sided PCB,Double-sided PCB,Multi-layer PCB-up to 30layers)

-Rigid-flexible PCB(1 to 16layers)

-Flexible PCB(1 to 8layers)

-HDI PCB

-All kinds of high class PCBs

PCB material we can use:

FR1, FR2, HB,CEM1,CEM3, FR4,High TG/CTI FR4,Halogen Free,Rogers,Aluminium based, Leadfree compatible, Hi Frequency.

Requested information for PCB assembly:

1.Gerber file of the bare PCB board

2. BOM (Bill of material) for assembly

3. Testing Guide & Test Fixtures if necessary

5. Schematic if necessary

Technical Specification

			English	Metric
1	Max. Panel Size		22" x 26"	550 x 650mm
2	Mechanical Drill
	Min. Finished Holes Size		0.004"	0.10mm
	Finished Holes Tolerance	PTH	±0.003"	±0.075mm
		NPTH	±0.002"	±0.050mm
		Press Fit	±0.002"	±0.050mm
	Aspect Ratio		9 : 1	9 : 1
3	Laser Drill
	Microvias diameter		0.004" - 0.006"	0.10 - 0.15mm
	Aspect Ratio		1 : 1	1 : 1
4	Min. Line Width/Spacing	½oz / 18um	0.003" / 0.003"	0.075 / 0.075mm
		1oz / 35um	0.006" / 0.006"	0.15 / 0.15mm
		2oz / 70um	0.008" / 0.008"	0.20 / 0.20mm
		3oz / 105um	0.010" / 0.010"	0.25 / 0.25mm
5	Registration
	Solder Mask		±0.003"	±0.075mm
	Layer to Layer		±0.0024"	±0.060mm
	Copper Feature to Holes(Outer)		±0.003"	±0.075mm
	Min. Plated Drills to Copper (inner)	2L - 8L	0.010"	0.25mm
		10L -22L	0.012"	0.30mm
6	Board Outline
	Edge to Edge Tolerance		±0.004"	±0.10mm
	Holes to Edge Tolerance		±0.004"	±0.100mm
	Min. Copper to Edge distance	Outer	0.010"	0.25mm
		Inner	0.016"	0.40mm
7	Max. Copper Thickness		4oz	140μm
8	Max. Board Thickness		0.189"	4.80 mm
9	Min Board Thickness	2L	0.008"	0.20mm
		4L	0.016"	0.40mm
		6L -22L	0.020"	0.60mm
10	Min. Core Thickness		0.004"	0.10mm
11	Min. Soldermask Dam		0.004"	0.10mm
12	Controlled Impedance (Ohm)		±7% - 10%	±7% - 10%
