300x1200 Led Recessed Panel Light

Led power:48W,total power consumption:54W
CE passed led driver,PF>0.9,power efficiency>85%

Different dimmable method for option: include PWM/ TRIAC(0-10V dimmable/ DMX dimmable/ RF dimmable)
SAMSUNG 5630 as light source is available accordingly.

Main specification for this smd led panel lamp:

18W(total 22w) LED Panel Light 300mm*600mm*11mm

36W(total 42w) LED Panel Light 300mm*600mm*11mm

36W(total 42w) LED Panel Light 300mm*1200mm*11mm
36W(total 42w) LED Panel Light 600mm*600mm*11mm
48W(total 54w) LED Panel Light 600mm*600mm*11mm
48W(total 54w) LED Panel Light 300mm*1200mm*11mm

1. High efficiency and energy saving compared to conventional fluorescents and the incandescent lamp which are equal bright.led light panel "led light panel supplier" is 50% energy-saving than CFL and 80% than incandescent lamp.
2.Long lifespan:Up to 50,000 hours, 8 times compare with CFL, 50 times compare with incandescent lamp.
3. Environment friendly:No RF interference, no buzzing noise, Low heat , no UV or IR radiation ,Not contain Pb and Hg, no pollution, green lighting.
4. No fluorescent flickering.Working with no flickering will protect your eyes better and comfortable.
5.Low power consumption, high intensity, low lumen attenuation.
6. Recessed mounted, easy installation.
7. Adopting low pressure constant current power supply

Installation Guide of this 300x1200 smd led panel light:


Storage Condition
The LEDs better be kept at<30℃ & < 60%RH.
Please avoid conditions which may cause the LEDs being corroded or discolored. The corrosion or discoloration might lower solderability or affect optical characteristics.
Please avoid rapid transition in ambient temperature, especially in high humidity environments where condensation can occur.

Packing method:
