4ch full 1080P HD-SDI DVR IGV-SDVR304 Features:

● Compression Method: H.264
● Real time recording support:
       1920x1080 with 120 Fps (NTSC);
       1920x1080 with 100 Fps (PAL)
● Preview resolution:
      1920x1080( NTSC ),
      1920x1080 ( PAL );
● Playback resolution: 4x1080P
● Hexaplex operation simultaneously: Preview, recording, playback, and network live, backup, playback
● 1 RJ-45 Ethernet connector, Static, Dynamic IP and DDNS, Support Internet Explorer and special client software
● Remote Control, PTZ, RS422, 2×USB, 1×IR Controller
● 2 SATA Hard Disk interface
● Backup: USB2.0 and Network
● Support remote view by Mobile phone

4ch full 1080P HD-SDI DVR IGV-SDVR304 Picture:

4ch full 1080P HD-SDI DVR IGV-SDVR304 Specification:

Model	IGV-SDVR304
Compression Format	H.264
Operating System	Embedded LINUX Operating System
User Interface	4-bit true color graphical menu, support for USB mouse operation, with menu notes
Preview resolution	4 x1080P
Real time recording support	*1920x1080 with 120 Fps (NTSC); 1920x1080 with 100 Fps (PAL)*
Video Input/Output	BNC 4CH In/ 1CH BNC Out/ 1CH VGA Out HDMI 1CH
Audio/Alarm Input/Output	RCA 4CH In/ 1CH Out /RCA 4CH In/ 1CH Out
Local Playback	1920x1080( NTSC ), 1920x1080 ( PAL );
Motion Detection	PAL 1310(130); NTSC 138(104) 4 grade available
Communication Interface	1 RJ-45 Ethernet connector, Static, Dynamic IP and DDNS , Support Internet Explorer and special client software
Hard Disk	*2 SATA Hard Disc interface*
USB port	2 pc (Mouse port and USB2.0 port)
VGA port	1pc(optional) Resolution:800×600, 1024×768
Special Feature	Support remote view by Mobile phone
Power Source	12V/5A
Working Temperature	0℃--+55℃
Working Humidity	10%--90%
Dimension	443mm×424mm×89mm,
Weight	9.6 Kg

Remark:

High-definition serial digital interface (HD-SDI) makes it possible to stream uncompressed Full HD 1080p video over coax wiring.

Why HD-SDI is better than HD IP Cameras?

1. Plug-N-Play. Just plug in the BNC and power.
2. By using existing coax cable, upgrading an analog camera to HD-SDI Megapixel
is simple.
3. IP cameras are more expensive, require a router / switch and usually a dedicated
network segment.
4. Unlike IP camera, HD-SDI require no special networking training.
