1.3mp Analog Cctv Camera With Sony Exmor Cmos Sensor

1.3mp Analog Cctv Camera With Sony Exmor Cmos Sensor

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

1.3MP Analog Security Camera IGV-IR33CMH:

Features:
• 1/3" Sony Exmor IMX138 Color CMOS
• The highest horizontal resolution 1200TVL
• Min.illumination 0.01Lux/F1.2(0Lux IR ON)
• ICR filter switching function,day&night surveillance
• Max.IR Distance 30m
• Conch appearance, multiple angles can be adjusted
• Lighting protection
• Waterproof level:IP66

Picture:

Specifications:

Model IGV-IR33CMH

CMOS IR Waterproof Security Camera

Pickup Device 1/3" Sony Exmor 138 Color CMOS Sensor

Pixels 1280(H)*720(V)

Resolution 1200TVL

Min.illumination Color:0.01Lux/F=1.2,Black and White:0Lux (IR ON)

White Balance Auto

Back Light Comp Auto

S/N Ratio >50dB

Electronic Shutter AUTO/ 1/50(1/60)-1/100,000sec

Day&Night ICR Cut

Operating Temp. -20℃ ~ 50℃

Sync. System Internal Sync

Video Output CVBS/1.0Vp-p/75Ω

Infrared Lamp 36 pcs φ5/850nm Infrared Lamp

IR Distance 30-45m

Power Supply DC12V ±10%

Power Consumption 100mA/420mA(IR ON)

Lens 4/6/8/4-9/2.8-12mm lens optional

size φ96*151mm

weight 1.1kg
