Hot Sale GraverMAX Jewelry Engraving Machine Jewelry Tools GraverMate Single Ended

Specifications:
Voltage:220V,50/60Hz,
Power: 80W, Weight: 7.5kg,
Speed: 1400rpm/min. Air pressure: 0-3kg/cm3
Dimensions: 230X230X230mm,
Packing Size: 320X300X310mm.

OPERATION:
1.Shut down the switch of AIR PRESSURE CONTROL KNOB & AUXILIARY AIR OPEN / CLOSE.
  KNOB FOR OUTLET BELOW to avoid the damage of pressure gauge and reducing valve due to
  strong air pressure.
2. After connecting all accessories with the machine, turn on the power. (The indicator light is shine )
3. Put the  ON/OFF Switch to Position (1) or (2).
4. Adjust the air pressure and the rotate speed, hold the handpiece like a table knife, step on the
    foot control to max ,adjust  AIR PRESSURE CONTROL KNOB slowly to the gauge show
    1.5-2kg/cm² , meanwhile adjust the STROKES PER MINUTE SELECTOR KNOB, in order to make
    the impact of  handpiece No.1 reach the maximum., then press the AIRPRESSURE CONTROL
    KNOB.
5. Loose the foot  control , the graver handpieces stop working, intall the graver tools into the handpiece .
    handpiece.
6. Turn the HANDPIECE SELECTOR KNOB to Switch Handpiece No.1 & No.2.
7.  When you using Hnadpiece No.2 –rotate handpiece , shut off the power, turn on AUXILIARY AIR
    OPEN / CLOSE.KNOB FOR OUTLET BELOW to adjust AIR PRESSURE CONTROL KNOB.
8. Step on the foot pedal to control impact.
