300*300mm 18W led panel light 3014 smd

Get Latest Price

Min. Order:: 1

Min. Order:: 1

Delivery Time:: 7 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Supply Ability:	1000
Certificate:	CE,RoHS,TUV,ETL

Product Description

300*300mm 18W square LED Panel Light | 1ft*1ft led panel light 18W 3014SMD | 300mm flat panel light fixture

Basic Parameters

Light Source:160pcs Lumenmax 3014 SMD
Luminous Flux:1400Lm
Light source wattage:16W
Total Power : 18W

PF>0.9
Base Options: wires
Input Voltage: 85~265VAC,50/60Hz nIsolated external constant power supply
Panel Input voltage:30~40VDC
Ra : 70~75
Luminous Efficiency: >75lm/w

Double side light out
Color Temperature:3000~3500K/4000~4500K/6000~6500K
Beam Angle:160 °
Heat sink + PMMA (diffuse plate)
Lifetime: 50,000 + hours
Size: L 300mm × W300 mm x H12.5mm
IP Rating:IP44 (Dustproof)
Body Temperature:<55℃ @Ta=25 ℃
CE,ROHS approved
Replacement:56W Grid CFL fixture

Features

Using high Brightness Lumenmax 3014 SMD chip,unit lumen up to 11~12Lm

Equipped with Japan Mitsubishi light guide plate whichhas a 80% rate of light guide.

External isolated constant current driver

No extra light diffusing,just be focused on the ground.No black spot or blinking

Environment-friendly, no UV or IR radiation, no heating effect and no poison.

Available running at 85~265VAC

Double Side light out

IP44,ideal for indoor use

Easy installation

3 years warranty

What to be awared of ?

1, Please make sure the 300*300mm( 1ft*1ft ) 18W led panel light 3014smd and its power supply are in good condition before installation

2, Only qualified electrician could install the panel light and electricity connection

3, Connect the Input end of Switching Power Supply with electric supply, usually Brown wire is the power line, blue wire is zero line , yellow wire is ground wire.

4, Do not install 300*300mm ( 1ft*1ft ) 18W led panel light 3014smd in ambient where has high temperature over like 55 celsius degree or over corrosive gas

5, Do not mix using special power supply with the power supply from different lamp

6, Don't throw away casually

Where to use ?

This 300*300mm ( 1ft*1ft ) 18W led panel light 3014smd is the best choice for room,hotel,museum office, corridor,etc
