3 channels ECG machine with auto-interpretation fuction

Features:
With auto-interpretation function; can assist doctor to diagnose;

Color LCD makes the images more clear for guaranteeing the reliability of the images ;

Designed with technology of Digital Signal Processing and Digital Isolation;

Synchronously 12 lead acquisition and printing 3 live leads record of them,Using high resolution thermal roll paper for recording ECG waveform, Multiple optional digital filter ( including baseline drift filter ),using auto-regulation baseline drift filter which can inhibit any baseline drift ,or curb caused by patient's movement and auto- optimize the position for printing;

Auto measurement / analysis system shows the real-time heart rate which makes it easier for
doctor's diagnosis;

Can store maximum of 100 patients' ECG data and enable user to replay data analyze and print it
from database;

High-speed USB interface and traditional RS-232 interface are both built–in for communicating
with computer as well as other devices;

Data can be received through one of the interfaces and displayed by the software which is also
provided by our company (optional);

Specifications:
LCD display: 640×480 TFT 5.7 inch graphic LCD

Lead: standard 12 leads

Sampling method: 12 leads synchronously acquisition

CMRR: >80dB, > 100dB (with AC filter)

Sensitivity: AUTO;2.5; 5; 10; 20 mm / mV

Paper speed: 6.25; 12.5; 25; 50 mm / s( ± 3%)

Paper size: 80mm x 30m roll type

Recording mode: Thermal Array printing

Power supply: AC: 110-230V (±10%) , 50/60 Hz±1Hz; 40 VA
DC: 14.4V rechargeable Li-ion battery

Package collocation:
Single unit size: 42cm x 26cm x 30cm Gross Weight: 7 kg

4 pcs/carton dimension : 42cm x 52cm x 60cm Gross Weight: 27kg

Normal collocation: roll paper, patient cable, power cable, limb electrode (limbnip) 4 pcs, chest
electrode ( sucking ball ) 6 pcs, AC electric fuse 2 purchase.
