wallmount 12v power supply
1.Features of wallmount 12v power supply :
- Input:AC 110-240V 50/60HZ
- Output:DC 12V 1A 1.2A 1.5A 2A /9V 1A 1.3A 1.5A 2A /8V 1A 1.3A 1.4A 1.5A 2A/5v 1A 1.5A 2A 2.5A 3A/6v 0.5a 1a 2a
- US,EU, AU,UK plug
- DC tips: you customize
- Output DC wire:1.2M
- Ripple noise:200mv
- Line regulation:+-5%
- load regulation:+-5%
2.Technical specification of wallmount 12v power supply:
|
Input voltage Rated Voltage: 100~240Vac |
|
Variation Range: 80V~280Vac Input Frequency Rated Frequency: 50/60HZ Variation Frequency: 47~63Hz |
|
Input current 0.5Amax. at any input voltage and rated, DC output rated load. |
|
Inrush Current 30Amax. @ 264Vac input Efficiency: 80% min at 100Vac input and output rated .Load. |
|
Turn on delay time: 80% min at 100Vac input and output rated .Load. 3S max. @ 100 Vac to 240 Vac input & Full load Rise time 20mS max. @ Rated load Hold up time: 5mS min. @ Full load &230Vac/50Hz input turn off at worst case |
|
Short circuit protection: The power supply will be auto recovered when short circuit faults remove. Over current Protection: The power supply will be auto recovered when over current faults remove Over Voltage Protection: The power supply will auto recovered when faults remove 120%~150%. |
|
Environmental requirement: Operating Temperature: 0~40°C ,full load , normal operation. Storage Temperature: -20~80°C with package Relative Humidity: 10%(0°C) ~90%(40°C) RH |
4.Warranty:
1. We provide 1 year warranty.
2. Normal Production according to the sample that confirmed by customers or customer's instruction. So please do give us right and confirmed instruction as well as check the sample carefully before you confirm.
3. Should you need any assistance with product problems please feel free to contact us.You will receive a prompt reply from us
5.Remarks:
1. delivery time:7 days (if quantity more than 4000Pcs,it will subject to our final
confirmation)
2. Payment: TT or western Union
A. Different ac power cord for US,UK, AU, EU to meet local market
B. You are buying a 100% Brand New Product, Guaranteed to be a Compatible !
C. We save your money and offer you quality product that meets safety & environmental standards !
D. our mission is to provide people with the electronics and computer parts to create and design their own figures .
E. We are growing and changing all the time. But our goal remains the same to keep providing "Customer Satisfaction" for our customers!
F. We are committed to offering high-quality and low-cost electronics, computer equipment and parts.
G. Our primary mission is your satisfaction with our products. We try our best to ensure at most customer satisfaction.
6.About us :
our company is the professional manufacturer and specialized in power adapter of laptop ,cctv camera ,mobile phone ,router, tablet etc
