Micro Brushless DC Pump DC50B-T Series Eco-friendly

Product Description

1 Sizes and weight 100.5mmx84.5mmx64mm;650g
2 Dimension of inlet 20mm O.D., 1/2inch threaded
3 Dimension of outlet 20mm O.D., 1/2inch threaded
4 Driving method Brushless, Magnetic , 3 phase
5 Pump material PA66+GF30% (optional)
6 Condition of use Continuously
7 Fluids Water, oil, acid and alkali solution etc
8 Max working temp 75C
9 Power consumption 2.5W~43.2W
10 Rated voltage 12Vdc or 24Vdc
11 Voltage used 5Vdc ~ 12Vdc or 5Vdc ~ 24Vdc
12 Max rated current 1.9A
13 Max flow rate 36L/Min(9.5GPM)
14 Max Static Head 4m(13ft)
15 Noise <40dB
16 Water proof class IP68(can be submersible installed)
17 Life span More than 30000hrs
18 Power supply Solar panel; DC electric source; battery

Product Feature

Pump body are completely potted by epoxy material, completely waterproof; can be continuously working without stop
Driven by program, sensor less, whole control circuit can be put outside
speed adjustable, can be adjusted by injecting external analog signals(0-5v) or by screwing potentiometer, for PWM-adjustable model should be customized
Can stand high temperature 100C
Stator and circuit board sealed by epoxy resin, completely water proof
Parameter can be adjusted flexibly, 12v pump's head can be from 0m to 8m, 24v pump's head can be from 0m to 15m
Locked-rotor and reverse connection protection
Automatic overload protection and over-temperature protection
Soft start with low in-rush current, great for PV panel
Can continuously work at temperature 100C

Application

Products can be widely applied to water heater pressurized plumbing mattresses, hot water circulation pumps, feet massage bathtub, humidifiers, air conditioners, washing machines, small-scale irrigation, medical equipment, cooling system, heating system, processes fountain pump, the food sector, solar water heaters, pumps, equipment of water circulating pump, washing machine circulation pump, soilless cultivation, sanitary pump, etc.
