24V Heavy Duty Speed Adjustable Micro DC Pump

24V Heavy Duty Speed Adjustable Micro DC Pump

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China

Product Description

24V Heavy Duty Speed Adjustable Micro DC Pump For High Temperature Water Pressurization/ Hot Water Circulation Max Lift 15m

Max Head 15m, Max Flow Rate 1200L/H

3phase brushless design, No spark, Absolute safety

Long Life Span, More than 30,000hrs

Can stand high temp. as 100 degrees Celsuis

Fit for continuously pumping boiling water or other fluids

Low Noise, Completely Water Proof

Low Start-up Current, fit for PV Panel

Fit for various hot water pumping/ circulation/ pressurization sys.

picture-1121

The right is inlet, while the left is outlet

Specifications of this Pump

&&Micro Size: 94.1x99x50

&&Light Weight: 650g

&&Dimension of Inlet and Outlet: 20mm O.D., 1/2 thread

&&Power Saving: 86W

&&Low Noise: Less than 40dB

&&Wide Working Voltage Range: 5-24Vdc (24V rated)

&&Max Static Head: 15m(49ft)

&&Max Flow Rate: 20L/Min (5.3G/Min)

&&Fluids: Water, oil, gasoline, acid and alkali solution, etc

&&Power Supply: can be battery, DC electric source or solar panel, etc

&&Super Long Life: >3years, can be continuously working, without maintenance

&&Water Proof Class: IP68 (Fit for submersible installation)

potentiometer-1121

potentiometer

About power/speed adjustation, there are two ways:

1)By potentiometer, to screw potentiometer to realize smooth change of flow current ranging from 0 to Max Flow Rate. The red wire is +5V dc, the black wire is ground, and the yellow wire is adjusting singal wire, locating with the central part of potentiometer. If you want to keep the highest working speed, just connect red wire and yellow wire together and black wire is vacant.

2)By injecting external changing 0-5V analog singal,just connecting our control signal with yellow one, connecting ground with black one and keep red one vacnat.(By the way, the analog signal can be realized through programming, fit for application like big music fountain or situations with self-adaptive needs)

If PWM singal injection is needed, pump can be customized according to your requirements if there is bulk goods demand. This one cannot be adjusted by PWM singal.

Typical Features

>>3Phase brushless, permanent magnetic rotor, maintenance-free, long life

>>Can stand high temperature 100 degrees Celsuis, continuously pumping boiling water

>>Locked-rotor and reverse connection circuit protection, automatic overload protection

>>Soft-start with low in-rush current

>>Small size, high efficiency, low consumption, low noise

>>Stator and circuit board sealed by epoxy resin, completely water proof

>>Sleeve and shaft with carbon fiber materials, better performance than ceramic and metal materials

>>Parameter adjustable, 24v pump`s Max head can be adjusted from 0m to 15m

>>Can be customized for friends with bulk product demand

DC50E-4-1121

This pump is a 24Vdc Brushless DC Pump with power adjustable function. It can be adjusted by hands(through potentiometer) or external signal(injecting 0-5V Analog Signal), suitable for Changing Environment/ Self-adaptation Application/ Experiments with unclear parameters. The shell material is PA66+GF30%, which the material itself can stand 200°C high temperature. The shaft is made of carbon fiber material, with better toughness and wear resistance than common-used material or ceramic material. And the screws are made of 304 stainless steel material, so as a pump whole it can stand continuous 100C high temperature environment, also can be corrosion-proof to liquid environment such as hydrochloric acid liquid used for pipe cleaning, etc.

Applications

This pump has a wide range of aplications, such as car cooling, motorcycle cooling and other vehicle cooling, landscaping and garden pumping, PC cooling system, humidifier, medical device, and many other cooling and circulation system.
