Features:

3Phase brushless, permanent magnetic rotor, maintenance-free, long life

Can stand high temperature 100 degrees Celsuis, continuously pumping boiling water

Locked-rotor and reverse connection circuit protection, automatic overload protection

Soft-start with low in-rush current, suitable for direct solar panel connection

Small size, high efficiency, low consumption, low noise

Stator and circuit board sealed by epoxy resin, completely water proof

Sleeve and shaft with carbon fiber materials, better performance than ceramic and metal materials

Parameter adjustable, 12V pump`s Max head can be adjusted from 2m to 8m

Specifications:

Sizes and weight:98mmx89mmx61mm; 600g

Dimension of Inlet and Outlet: 20mm O.D., 1/2 thread

Power Saving: 43W

Low Noise: Less than 40dB

Wide Working Voltage Range: 5-12Vdc (12Vdc rated)

Max Static Head: 8m (26ft)

Max Flow Rate: 17L/Min (4.5G/Min)

Fluids: Water, oil, gasoline, acid and alkali solution, etc

Power Supply: can be battery, DC electric source or solar panel, etc

Super Long Life: >3years, can be continuously working, without maintenance

Water Proof Class: IP68 (Fit for submersible installation)

Parameters (The technical specification only for reference, it can be customized)

This pump has a wide range of applications,  motorcycle cooling and other vehicle cooling, landscaping and garden pumping, PC cooling system, humidifier, medical device,such as car cooling,and many other cooling and circulation system

Note:

1. Working at rated voltage.The positive pole is brown wire, the negative pole is blue wire.

2. This pump is centrifugal pump, it can't vent the air automatically, so it must be operated by submersible installation.(if outside water installation, you should make sure it is installed blow the liquid surface)

3. When blocking, long-running is not allowed.

4. Preventing any hard particles entering the pumps.
