24V Water pump submersible No Spark Absolute Safety  For water cooling Air Conditioning/Dehumidifier Application

For Pump, Water plays three roles: 1, the medium being pumped; 2, coolant of pump; 3, lubricant of pump.

Features:

Brushless, permanent magnetic rotor, maintenance-free, long life

Small size, high efficiency, low consumption, low noise

Stator and circuit board sealed by epoxy resin, completely water proof

Parameter adjustable, 24v pump`s head can be adjusted from 3m to 7m

Can be fixed on the vessel wall with sucking disk

Can be customized for friends with bulk product demand

Specifications:

Sizes and weight:83mmx63mmx48mm; 300g

Dimension of Inlet and Outlet: 13.8mm / 10mm

Power Saving: 27W

Low Noise: Less than 35dB

Wide Working Voltage Range: 5-12Vdc (12Vdc rated)

Max Static Head: 7m (23ft)

Max Flow Rate: 10.3L/Min (2.73G/Min)

Fluids: Water, oil, gasoline, acid and alkali solution, etc

Power Supply: can be battery, DC electric source or solar panel, etc

Super Long Life: >3years, can be continuously working, without maintenance

Water Proof Class: IP68 (Fit for submersible installation)

This pump has a wide range of applications, such as mini aquarium, fountain, landscaping and garden pumping, micro PC cooling system, humidifier, medical device, and many other cooling and circulation system.

How to Choose pump:

1. Make sure the working voltage, current, head and flow. The Max head means the static head. The pump can lift to the max heightwhen there is no flow. If you want special flow at special height, you must choose more higher head than the height you want to pump(refer to the above Head-Flow Curve graph).

2. Make sure the dimension(threaded interface or not, the direction and diameter of outlet and inlet).

3. Working environment(temperature and medium).

4. Other functional requirements, such as time control, motion control, pressure control, flow control, and speed adjustment.

Note:

1. Working at rated voltage (DC24V/1A ). The positive pole isred wire, the negative pole is black wire.

2. This pump is centrifugal pump, it can't vent the air automatically, so it must be operated by submersible installation.(if outside water installation, you should make sure it is installed blow the liquid surface)

3. When blocking, long-running is not allowed.

4. Preventing any hard particles entering the pumps.
