addition high transparent food grade liquid silicone rubber for cake molding
- Payment Type:
- T/T, L/C, Western Union
- Incoterm:
- FOB
- Min. Order:
- 200 Kilogram
- Min. Order:
- 200 Kilogram
- Delivery Time:
- 7 Days
- Transportation:
- Ocean, Land, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | china |
|---|---|
| Productivity: | 200ton/month |
| Supply Ability: | 200ton/month |
| Payment Type: | T/T,L/C,Western Union |
| Incoterm: | FOB |
| Certificate: | ISO9001 |
| Transportation: | Ocean,Land,Air |
Descripation:
RTV-2 mold making addition silicone rubber is generally named as two-part silicone rubber that vulcanizes at room temperature.Part A is a flow able liquid ,part B is the platinum catalyst.
Characteristical:
• Easy to use
• Almost nil shrinkage
• Use platinum catalyst
• Excellent non-stick effect
• High degree of precision in reproduction
• High dimensional stability over time and non-deformability
• Food grade silicone (environmental,odorless and nontoxic)
• High resistance to high temperature and aging(resist -60 to 200°C)
• High chemical resistance to aggressive components of some types of resins
• Good tear strength (this feature ensures higher resistance to wearing and shearing)
Application:
• PU resin casting
• General mold making
• GRC and concrete molding
• Superior manual mold design
• Food grade molding application
• Rapid prototyping(urethane casting/silicone tooling/vacuum casting)
Parameter:
Catalyst
| Working and cure times at room temperature (25°C)Catalyst | Appearance | Base/catalyst mixing ratio by weight | Pot life Time mins | De-mold Time |
| P10 | clear | 100:10 | 60mins | 24hrs |
| P11 | clear | 1:1 | 30-40mins | 24hrs |
Silicone
| Characteristical before curing | Characteristical after curing | ||||||
| Item NO. | Appearance | Viscosity | Hardness | Tear strength | Tensile Strength(Mpa) | Elongation break (%) | Linear Shrinkage(%) |
| Mpa.s | Shore A | (KN/m) | |||||
| RTV1311 | transparent | 15000±2000 | 10±2 | 31±2 | >2.7 | 750 | <0.1 |
How to make mold?
1.Mixing
Please weight 10 Part A base and 1 parts of platinum Catalyst in a clean container.Thoroughly stir Part A base silicone before use, as filler separation may occur upon prolonged storage. Mixing Part A and Part B evenly until part B completely dispersed in the base. Hand or mechanical mixing can be used,but do not for an extended period of time or allow the temperature to exceed 35°C. Mix suitably small quantities to ensure thorough mixing of base and catalyst.
It is strongly recommended that entrapped air be removed in a vacuum chamber,allowing the mix to completely expand and then collapse. After a further 1-2 mins under vacuum,the mix should be inspected and can be used if free of air bubbles. A volume increase of 3-5 times will occur on vacuum de-airing the mixture. So a suitably large container should be chosen.
2.Pouring the mixture and curing
Pour the mixed Part A base silicone and part B platinum catalyst as soon as possible onto the original,avoiding air entrapment.The catalyzed material will cure to a flexible rubber within 24 hours(or faster by different mixing ratio or room temperature).
Storage:
When stored at or below 30°C in the original unopened containers,SILASTIC Base and platinum Catalyst have a usable life of 12 months.from the date of production.After 12 months stock,pls use the Stir to mixing the Part A silicone for some mins, then the silicone can be use again,no influence for other performance.
