Shoe Mold Silicone Rubber
  • Shoe Mold Silicone Rubber
  • Shoe Mold Silicone Rubber
  • Shoe Mold Silicone Rubber
  • Shoe Mold Silicone Rubber
  • Shoe Mold Silicone Rubber
Shoe Mold Silicone Rubber
Shoe Mold Silicone Rubber
Shoe Mold Silicone Rubber
Shoe Mold Silicone Rubber
Shoe Mold Silicone Rubber

Shoe Mold Silicone Rubber

Min. Order:
100
Min. Order:
100
Delivery Time:
3 Days
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: Guangdong China
Supply Ability: 8tons perday
Certificate: RoHS.MSDS.SGS ISO9001:2000 ISO 9000/9001/9004/19011: 2000
Product Description
Product Description

Brief description:

Shoe mold silicone rubber
A. mainly used for shoe soles mold making

B. Two-component silicone rubber with tin-catalyst

C. Cured under room temperature

D. low shrinkage

E. excellent flexibility & easy demould

Detailed description:

Shoe mold silicone rubber applications

Shoe mold silicone rubber is mainly used for shoe molds, sand casting, sole sampling, plaster models, simple products, products with non-complex patterns, as well as product models with stable size and non-deformation.

Shoe Mold Silicone Rubber features:

A.      Two-component silicone rubber with tin-catalyst

B.      Cured under room temperature

C.     low shrinkage

D.     excellent flexibility & easy demould

Shoe Mold Silicone Rubber Standard Datasheet:

Model

Appearance

Viscosity (cps)

Hardness (A°)

Tensile Strength (Mpa)

Tear Strength (KN/m)

Elongation (%)

Mixing ratio (%)

Pot life(H)

Demould time(H)

218

White

15000

182

1.3

5

300

2~3

0.5~2

2~4

 Shoe Mold Silicone Rubber Using Instruction:

The component A of shoe Mold Silicone Rubber is white flowing liquid and the component B is the curing agent. For example, take silicone rubber of 100g and add 2% curing agent for  mixing evenly. After the silicone rubber and the curing agent are completely mixed, put the silicon into a vacuum machine for deairing to remove the bubbles. After deaired, pouring the liquid silicone rubber into the product to be duplicated or into the mold frame.

Notes:

Shoe mold silicone rubber is used for pouring or brushing technique. That is to say, fix the product or sole model to be duplicated onto a plane plate, then enclose the plane frame with wooden plates to prevent the leakage of the silicon , mix the silicone rubber and the curing agent evenly according to the mixing ratio of 100 : 2 and pour them onto the sole model, then brush evenly with a wooden plate or a brush, and fill up the mold frame with gypsum after the silicone rubber is dried



Any further information required of shoe mold silicone rubber, pls feel free to contact Mr sean ( sales manager)
